Altronix HubSat4D Installation Manual
  1. Manuals
  2. Brands
  3. Altronix Manuals
  4. Switch
  5. HubSat4D
  6. Installation manual
Altronix HubSat4D Installation Manual

Altronix HubSat4D Installation Manual

Passive utp transceiver hub with integral camera power
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Video • Data • Power
Passive UTP Transceiver Hub
with Integral Camera Power

Installation Guide

Models Include:
HubSat4D
- Four (4) Channel Passive UTP Transceiver Hub with Integral Camera Power
HubSat42D
- Four (4) Channel Passive UTP Transceiver includes four (4) HubWayAv
Video Balun/Combiners
HubSat43D
- Four (4) Channel Passive UTP Transceiver includes four (4) HubWayDv
Video Balun/Combiners
Rev. 112408
More than just power.
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HubSat4D and is the answer not in the manual?

Questions and answers

Related Manuals for Altronix HubSat4D

Summary of Contents for Altronix HubSat4D

  • Page 1: Installation Guide

    Video • Data • Power Passive UTP Transceiver Hub with Integral Camera Power Installation Guide Models Include: HubSat4D - Four (4) Channel Passive UTP Transceiver Hub with Integral Camera Power HubSat42D - Four (4) Channel Passive UTP Transceiver includes four (4) HubWayAv Video Balun/Combiners...

  • Page 2: Specifications

    4 cameras over a single CAT-5 or higher structured cables back to the HubWay, HubWayLD or HubWayLDH Passive and Active UTP Transceiver Hubs. In addition, the HubSat4D provides power to these cameras locally to eliminate the possibility of voltage drop associated with long cable runs.
  • Page 3 3. Set the voltage output selector switch for either 24VAC or 28VAC (Fig. 1d, pg. 4). HubSat4D for use as a Remote Accessory Module with HubWay/HubWayLD/HubWayLDH UTP Transceiver Hubs. After completing steps 1-4 of Installation Instructions HubSat4D Passive UTP Transceiver Hub with Integral Camera Power proceed with the following.
  • Page 4 1e - LED(s) 1-4: Power output indicators. equipment (DVR). 1f - Data: RS422/RS485 input from head end equipment 1i - Channels 1-4: CAT-5 or higher structured cable (DVR) for PTZ control. to cameras. Pin out configuration (Fig. 3, pg. 6). - 4 - HubSat4D...

  • Page 5: Hubwayav, Hubwayav2, Hubwaydv, And Hubwaydvi Video Balun/Combiners

    Data to Cable from Data to Connector to Camera to Camera of Camera HubSat4D Camera HubSat4D Camera of Camera HubWayAv passes AC voltage from pins HubWayDv/HubWayDvi converts AC voltage to DC 4, 5, 7, 8 to terminals marked [AC Power] voltage from pins 4, 5, 7, 8 to terminals marked (Fig.
  • Page 6 7 - White/Brown [AC 2] 8 - Brown [AC 1] Fig. 4 - CAT-5 Structured Cable Wiring Color Codes for Video 1-4 Port on HubSat4D board 1 - White/Orange [ VIDEO OUT 4 ] 2 - Orange [ VIDEO OUT 4 ]...
  • Page 7 Typical Application Drawing HubSat4D Passive UTP Transceiver Hub with Integral Camera Power: Fig. 6 Head End Equipment (DVR) Monitor RS485 Data Video Data Power Data CAT-5 Video HubWayAv Power CAT-5 Video Balun Combiner 24VAC PTZ HubWayDv/Dvi Camera Video Balun Combiner...

  • Page 8: Enclosure Dimensions

    5.25” 1” (25.4mm) (133.35mm) (25.4mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 website: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A. IIHubSat4D L01P MEMBER - 8 - HubSat4D...
