Video • Data • Power
Passive UTP Transceiver Hub
with Integral Isolated Camera Power
Installation Guide
Models Include:
HubSat4Di
- Four (4) Camera Channels
HubSat42Di
- HubSat4Di w/four (4) HubWayAv Video Balun/Combiners for 24VAC Cameras
HubSat43Di
- HubSat4Di w/four (4) HubWayDv Video Balun/Combiners for 12VDC Cameras
TM
Rev. 090209
More than just power.
Advertisement
Table of Contents
Related Manuals for Altronix HubSat4Di
Summary of Contents for Altronix HubSat4Di
-
Page 1: Installation Guide
Integral Isolated Camera Power Installation Guide Models Include: HubSat4Di - Four (4) Camera Channels HubSat42Di - HubSat4Di w/four (4) HubWayAv Video Balun/Combiners for 24VAC Cameras HubSat43Di - HubSat4Di w/four (4) HubWayDv Video Balun/Combiners for 12VDC Cameras Rev. 090209 More than just power. -
Page 2: Specifications
24VAC or 28VAC electronically isolated fuse protected outputs with surge suppression. Optionally, the HubSat4Di can be used as an accessory module to transmit video from up to 4 cameras over a single CAT-5 or higher structured cable back to the HubWay, HubWayLD or HubWayLDH Passive and Active UTP Transceiver Hubs. In addition, the HubSat4Di provides power to these cameras locally to eliminate the possibility of voltage drop associated with long cable runs. - Page 3 2. Plug the RJ45 connector at one end of the CAT-5 or higher structured cable into the RJ45 jack marked [PVD1] on HubSat4Di (Fig. 1i, pg. 4). Plug the RJ45 connector at the opposite end of the CAT-5 or higher structured cable into the RJ45 jack of the Video Balun/Combiner to be installed at camera 1.
- Page 4 3. Set illuminated master power disconnect circuit breaker to the RESET (ON) position (Fig. 4a, pg. 6) power LEDs (Green) of the HubSat4Di will illuminate when AC power is present (Fig. 1e, pg. 4) and HubWayAv, HubWayDv or HubWayDvi Video Balun/Combiner LEDs will illuminate indicating power is present (Fig. 2b, 2d, pg. 6).
- Page 5 1. Set illuminated master power disconnect circuit breaker to the (OFF) position (Fig. 4a, pg. 6). 2. Connect one end of the coaxial cable to the BNC connector marked [Video1] on HubSat4Di (Fig. 1a, pg. 4). Connect the opposite end of the coaxial cable to the BNC video output of camera 1 (Fig. 6a, pg. 7).
- Page 6 Fig. 2d Green Power LED Red Power LED Structured Structured Cable from AC Power Cable from 12VDC Power To BNC To BNC HubSat4Di to Camera HubSat4Di to Camera Connector Connector of Camera of Camera Data to Data to Camera Camera...
- Page 7 Typical Application Drawing for HubSat4Di as a Passive UTP Transceiver Hub with Integral Camera Power: Fig. 5 Head End Equipment (DVR) Monitor RS485 Data Video Data Power Data CAT-5 Video HubWayAv Power CAT-5 Video Balun 24VAC PTZ Combiner HubWayDv Camera...
-
Page 8: Enclosure Dimensions
Enclosure Dimensions: 8.5”H x 7.5”W x 3.5”D Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 website: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. IIHubSat4Di D14J MEMBER - 8 -...
