P1600 BILL OF MATERIALS
511-16001-00
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
PART NUMBER
002-02088-00
006-15210-00
111-00274-00
111-00275-00
111-00276-00
111-00277-00
111-00293-00
111-00294-00
111-00295-00
111-00296-00
111-00554-00
511-01900-00
511-04238-00
911-01204-00
LIFT, PIVOT P1600
DESCRIPTION
TUBE, .875" X 1.063" X 26"
CAP, VINYL 2" SQ. LIFT CORNER
WELD'T, FRAME BEAM "A"
WELD'T, FRAME BEAM "B"
WELD'T, PIVOT ARM
ASS'Y, P1600 WINCH
ASS'Y, 2" PULLEY BLOCK W/ 7 LINKS
ASS'Y, P1600 SIDE FRAME (R)
ASS'Y, P1600 SIDE FRAME (L)
ASS'Y, P1600 CRADLE
ASS'Y, ADJUSTABLE LEG – 48"
WHEEL, 36"
FASTENERS, P1600 LIFT
POST, WINCH – 24"
QTY
2
3
1
1
2
1
1
1
1
1
4
1
1
1
Advertisement
Related Manuals for Floe P1600
Summary of Contents for Floe P1600
- Page 1 WELD’T, FRAME BEAM “B” 111-00276-00 WELD’T, PIVOT ARM 111-00277-00 ASS’Y, P1600 WINCH 111-00293-00 ASS’Y, 2” PULLEY BLOCK W/ 7 LINKS 111-00294-00 ASS’Y, P1600 SIDE FRAME (R) 111-00295-00 ASS’Y, P1600 SIDE FRAME (L) 111-00296-00 ASS’Y, P1600 CRADLE 111-00554-00 ASS’Y, ADJUSTABLE LEG – 48” 511-01900-00 WHEEL, 36”...
- Page 2 P1600 SUB-ASSEMBLIES PART NUMBER DESCRIPTION 111-00277-00 ASS’Y, P1600 WINCH 001-70103-00 HHCS, 3/8-16 X 3/4” 18-8 SS 001-70105-00 HHCS, 3/8-16 X 1” 18-8 SS 001-71017-00 FLAT WASHER, 3/8” SAE SS 18-8 001-76071-00 NUT, NYLOCK 3/8-16 ALUM. 002-03327-00 MOUNT, WINCH – 9.5”...
- Page 3 P1600 Frame Exploded View A LIFT P/N 511-16001-00...
- Page 4 P1600 FASTENERS PART NUMBER DESCRIPTION 511-04206-00 FASTENERS, P1600 LIFT 001-70010-00 HHCS, 1/4-20 X 1-3/4” 18-8 SS 001-70103-00 HHCS, 3/8-16 X 3/4” 18-8 SS 001-70107-00 HHCS, 3/8-16 X 1-1/4” 18-8 SS 001-70110-00 HHCS, 3/8-16 X 1-3/4” 18-8 SS 001-70115-00 HHCS, 3/8-16 X 3” 18-8 SS 001-70219-00 HHCS, 1/2-13 X 4”...
- Page 5 P1600 Frame Exploded View B NOTE: ADDITIONAL VIEWS ON LIFT P/N 511-16001-00 FOLLOWING PAGES VIEW 1 VIEW 4 VIEW 3 VIEW 2 VIEW 5...
- Page 6 P1600 Frame Exploded Views 1 & 2 LIFT P/N 511-16001-00 VIEW 1 VIEW 2...
- Page 7 P1600 Frame Exploded Views 3-5 LIFT P/N 511-16001-00 VIEW 3 VIEW 4 VIEW 5...
