Page 1
OWNER’S MANUAL V-2000 V-2600 V-3600 V-4600 V-2602 PWC Boat Lift Systems Watch our customized boat lift setup and installation video: www.floeintl.com/manuals-information Retain this manual for future reference manual winch or dc winch with electronic control system AttENtiON AttENtiON AttENtiON Read and follow all safety rules and operating instructions carefully before attempting to install or operate lift system.
Because your FLOE boat lift is engineered to lift and support a tremendous amount of weight, it is critical that you operate it safely. Anyone who operates this lift must read the entire owner’s manual before operating the lift to make sure they are able to operate it properly and enjoy all of its features to the fullest.
If you do not understand any of these instructions, CAUtiON please ask your dealer or call FLOE Customer Service at 218-426-3563 or toll free 800-336-6337. You can be killed or seriously injured if you don’t follow instructions.
Page 4
Never overload a boat lift. See capacities/ specifications for important information FLOE lift systems have not been tested in regarding the boat’s actual weight and boat brackish or salt water conditions. Lift failures lift capacity limitations.
______ I understand that if my lift is equipped with a canopy it must be properly secured or it could blow over and cause damage not covered under warranty. ______ I understand that I must discontinue using the lift immediately and contact my FLOE dealer if any unusual sounds or functionality are present.
LiFt CAPACitiES 3. Determine that the boats center of gravity (CG) is centered between the two main lift beams The boat should be parked so that the boat’s CG It’s recommended that the total loaded weight of or balance point is centered between the two the water craft doesn’t exceed 75-85% of the to- main lift beams (Illustration B).
It is common for published dry weights One way to determine whether the lift’s capac- to be considerably lower than actual loaded ity is adequate is to log onto FLOE’s website, weights. Lift and/or boat damage due to www.floeintl.com, and click on the Boat Lift overloading is not covered by your warranty.
WiNCh SELECtiON & USE SELECtiNg thE BAttERY You can customize your FLOE vertical lift with the Before assem- winch style that best fits your needs and budget. bling or using The DC battery-powered winch offers an effortless the DC Winch...
Option #2: To maintain a battery charge with the optional FLOE 12-Volt solar panel (Fig. 6). mount panel per included instructions and wire it to the battery as shown in Fig. 7. Be sure the panel faces the sun during peak daylight hours.
Page 13
DC WiNCh iMPORtANt iNFORMAtiON ADVANCED & gENERAL MANitENANCE SWitCh • When used on a Floe Vertical Boat Lift, this winch must be properly assembled with two pulley blocks CONtROL and a triple-line cable system. Any other assembly (ASC) would greatly reduce the winch/cable capacity and is not recommended.
CONNECtiNg AND USiNg thE WiRED CONNECTING AND USING WARNING REMOtE THE WIRED REMOTE The DC Winch with Advanced The magnet holder on the cradle beam must remain Fig. 16 The DC Winch with A d v a n c e d System Control (ASC) comes intact and must be checked periodically.
Then attach the combination receiver to the post. See mitters. Contact your local dealer or FLOE International. assembly instructions for more details. RAISING AND LOWERING Should the remote fail to perform properly, contact your wireless remote plugs into the 7-in.
Is the lift overloaded or has it exceeded its max FLOE has matched a winch and cable pull style to each run/cycle on time lift model to assure optimal performance. The V2000 lift b.
Page 17
RAiSiNg AND LOWERiNg thE MAiN CRADLE LiFt BEAMS Before raising or lowering the main cradle lift beams, it is important that you understand how to operate the remotes, what to do should the remotes fail, and how to ensure that the lift is both level and in adequate water depth.
Never adjust leveling legs (up or down) With the exception of the winch cables, all of FLOE!s ver- with a boat on the lift. The added weight tical lift cables are made of aircraft-quality stainless steel.
Page 19
FLOE tOOL kit on an individual leg and need to FLOE has provided a kit with four tools for use proceed to the with your VSD boat lift. other legs. 1. Flush Style Grease Gun Tip (Fig. 27) (for greasing the ball-screw mechanism) Fig.
The weight and removed on a seasonal basis. FLOE has of the boat and lift must be supported by the several accessory options designed to make this sand pads only.
To see a Float & Roll in use, view FLOE’s free marine VHS or DVD video, “A Look Into FLOE Dock & Lift Systems” or go to www.floeintl.com and play the video found under Boat Lifts > Accessories > Install/Removal.
BUNk SELECtiON & SEt-UP DANgER FLOE offers four different lift bunk styles to ac- Fig 41 commodate a wide variety of boat and pontoon Never attempt to adjust hulls.
DEtERMiNiNg thE PROPER WiDth PROPER ADJUStMENt The proper width of the bunk system depends on Ideally the pads in the rear will be spread out to- the contour of the boat hull. As a rule of thumb, wards the edges of the hull to better distribute the bunks should be spread as wide as possible.
PONtOON FULL LENgth BUNk/ gUiDE-iN SYStEM FOR tWiN & tRi-tOONS Specially designed for pontoon boats, FLOE’s pontoon guide-in/bunk system provides excellent guidance for a craft entering the lift. Constructed of aluminum and composite, this kit (when cor- Guide Edge rectly installed) functions to both guide the boat into the lift and then raise and support the craft by its frame.
PRO-PARK VERTICAL GUIDES The FLOE vertical guide-in system is designed to guide the boat by its rub rail so it never touches or mars the hull. It has an infinite adjustment range limited only by the width of the lift, to allow for a perfect fit.
Technically, two pairs of single guides would be best to help safely guide the boat into the lift. However, FLOE recommends at least one pair of double guides for the lift’s entry because this style has two vertical guides mounted ahead of the lift structure.
PROPER CANOPY FRAME POSitiONiNg The FLOE canopy system is adjustable vertically and horizontally. Detailed instructions on how to make these adjustments are included with the canopy system. Once the boat’s proper position is known, follow the simple steps below to ensure proper canopy placement as shown in Figs.
END FRAME ADJUStMENt CANOPY FABRiC iNStALLAtiON All canopy frames are equipped with the adjust- 1. Place fabric over the frame system and adjust able end frame feature. This feature makes instal- where necessary for a uniform fit. lation and removal easier and pulls the canopy 2.
Mesh end canopies are available for high wind areas (Fig. 59). Screw-auger anchors are commonly used to secure mobile homes and can be purchased at most hardware stores. They can also be purchased from a FLOE boat lift dealer. (1) Pull straight down...
CANOPY FOLDiNg iNStRUCtiONS pass through the fabric. It is recommend that the canopy be kept taut using FLOE’s horizontal fabric 1. Lay can- tensioner and Quick-Clip with elastic tension belt system. A taut canopy fabric promotes water run- clean, flat off and will minimize water penetration.
• If the lift receives wind damage or is moved or blown over by the wind, a full inspection (preferably by a trained FLOE dealer or other knowledgeable professional) must be completed before the lift is used. • Grease lift as outlined in this manual. See Fig. 71 on the following page.
INSPECTIONS & MAINTENANCE Fig. 70 Sheave Locations (Total of Seven) There is one sheave that comes with the winch in a dou- continued ble-pull system. In the lift itself there is one sheave at each end of the two side cradle lift beams and one at each end of the front cradle lift beam.
Page 33
G R E A S I N G T H E E A S Y- L E V E L L E V E L I N G L E G The Easy-Level leveling leg must be greased at least once annually. This should be done prior to winter storage if the lift is removed seasonally.
AdditionAl WArrAnty informAtion including Exclusions And oWnEr’s rights FLOE International, Inc. (manufacturer) will not be responsible for any costs incurred for, or as the result of, unauthorized repairs or improper assembly. Unau- thorized repairs may void the warranty on the repaired part(s). This warranty does not cover damage, malfunction or faulty operation resulting from overload, misuse, wind, storms, ice, salt/brackish water applications, negligence, being hit by watercraft of any kind and any other ‘Act of God’.
Page 51
And LAbor WArrAntY FLOE International, Inc. will repair or replace, at their option, any portion of the lift system which fails as a result of a defect in material or workmanship during the first two years after the date of purchase. FLOE INTERNATIONAL, INC. reserves the right to inspect and perform repairs at its main facility (F.O.B.) McGregor, Minnesota.
Page 53
Mcgregor, MN 55760-9514 WARRANtY REgiStRAtiON CARD NOtE: This card must be completed by the FLOE Retail Dealer or the customer and returned to FLOE INTERNATIONAL, INC. within *15 days of purchase, to validate warranty. Please affix proper postage before mailing. Please complete all information requested.
Page 54
ATVs, and is great for yard work, engineered with custom extruded aluminum components and hunting, camping, cabin travel, construction, stainless steel leveling cables. FLOE lifts are designed for rental, shopping and almost any other use easy installation and removal.
Page 55
Thank you for purchasing a quality FLOE boat lift. Understanding the information in this manual should help you to keep your boat lift in optimal working condition for many years of worry-free enjoyment. Please take the time to record this important...
