TIG up/down torch (8-pole)

Up/down torch with one torch trigger
Figure
Functions
Welding current on/off
Secondary current (tapping function)
Increase welding current (up function
Decrease welding current (down function
Welding current on/off
Secondary current (tapping function)
Increase welding current via current jump
Decrease welding current via current jump
1
> see 5.1.9.1 chapter
2
> see 5.1.9.3 chapter
3
> see 5.1.9.4 chapter
099-00T401-EW501
01.02.2022
Operating ele- Explanation of symbols
ments
BRT 1 = torch trigger 1
)/(latched operating mode)
1
)
2
)
2
)/(latched operating mode)
1
3
3
Functional characteristics
