monitoring data are accessible for visualisation and analysis purposes.
EVBox Smart Charging is not only a monitoring solution but also an energy traffic controller. This
functionality allows automatic interaction with the energy traffic within the installation, which is
based on predefined logic embedded in the system.
2.2 Kit overview
Smart Charging is offered in 4 versions:
•
Smart Charging 1-phase
•
Smart Charging+ 1-phase
•
Smart Charging 3-phase
•
Smart Charging+ 3-phase
2.3 Hardware pre-configuration
IMPORTANT: The components in the kit (Power Box, CT hub(s) and Wi-Fi Connect or
Genius unit) are pre-configured and are specific to one kit. These components cannot
be used with a different kit.
Typical device combinations are:
Smart charging: CT Hub - Power Box - Wi-Fi Connect
Smart charging+: CT Hub - Power Box - Genius
2.4 Compatibility of Smart Charging with EVBox charging
stations
Product
BusinessLine
G3 onwards
HomeLine
G3 onwards
Elvi
Smart charging compatibility (July 2019)
Supported.
Connection via RS485 on ChargePoint PCB.
Refer to below schematic.
Supported.
Connection via RS485 on ChargePoint PCB.
Refer to below schematic
Supported from Q4 2019 onwards.
Earlier Elvi charging stations are not compatible.
7
