EVBox Elvi
fixed cable
fixed cable
Installation and user manual
Part A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elvi and is the answer not in the manual?

Questions and answers

Related Manuals for EVBox Elvi

Summary of Contents for EVBox Elvi

  • Page 1 EVBox Elvi fixed cable fixed cable Installation and user manual Part A...
  • Page 2 I'm here! Let's get started.
  • Page 3 EVBox Elvi fixed cable fixed cable Installation and user manual Part A...

  • Page 5: Table Of Contents

    4.3. Install the wall dock 4.4. Install the station 4.5. Commissioning 4.5.1. Register the charging station with CMP (optional) 4.5.2. EVBox Connect app 4.5.3. Pairing 4.5.4. Configure the installer mode settings 4.5.5. Configure the user settings 4.5.6. Configure a Hub-Satellite installation...
  • Page 6 5. OPERATING INSTRUCTIONS 5.1. Charge with the charging station 5.1.1. Start and stop a charging session 5.1.2. LED indicator ring 5.2. Troubleshooting 6. MAINTENANCE INSTRUCTIONS 6.1. Maintenance by user 6.2. Maintenance by qualified electrician 6.2.1. Remove the station 6.2.2. Replace the charging cable 6.2.3.

  • Page 7: Introduction

    1. Introduction 1. Introduction Thank you for choosing this EVBox Elvi. This Installation and User Manual tells you how to install and use the station. You must carefully read the safety information before you start. 1.1. Scope of the document Keep this manual for the entire life cycle of the EVBox Elvi.

  • Page 8: Certification And Compliance

    US contact information: 1930 Innovation Way, Suite 200, Libertyville, IL 60048, USA www.evbox.com Canadian Regulatory Statements This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference.

  • Page 9: Product Classification

    1. Introduction radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotopically radiated power (e.i.r.p.) is not more than that necessary for successful communication. This equipment complies with the ICES RF radiation exposure limits set forth for an uncontrolled environment.

  • Page 10: Important Safety Instructions

    2. IMPORTANT SAFETY INSTRUCTIONS 2. IMPORTANT SAFETY INSTRUCTIONS Read these instructions before you install this product. SAVE THESE INSTRUCTIONS. WARNING: When using electric products, basic precautions should always be followed, including the following: 2.1. INSTRUCTIONS PERTAINING TO RISK OF FIRE OR ELECTRIC SHOCK DANGER: Not following the installation and user instructions given in this manual will result in the risk of...
  • Page 11 2. IMPORTANT SAFETY INSTRUCTIONS • Contact your installer if you suspect that the charging station is damaged. DANGER: Some electric vehicles release hazardous or explosive gasses when charging which will result in the risk of explosion, which will cause severe injury or death. •...

  • Page 12: General Safety Instructions

    2. IMPORTANT SAFETY INSTRUCTIONS • Use this charging station to charge compatible electric vehicles only. Refer to the charging station specifications in this manual for details. • Refer to your vehicle user manual to check if your vehicle is compatible. WARNING: Exposure of the charging station or the charging cable to heat or flammable substances can result in damage to the charging station, which will cause injury or death.

  • Page 13: Moving And Storage Precautions

    2. IMPORTANT SAFETY INSTRUCTIONS • Do not allow children to operate the charging station. Adult supervision is required when children are near a charging station that is in use. • Do not put fingers into the electric vehicle connector. CAUTION: Using adapters, conversion adapters or cord extensions with the charging station may result in technical incompatibilities and can result in damage to the charging station, and thus cause injuries or death.

  • Page 14: Product Features

    Charge card reader This is the area where you scan your charge card or key fob. Depending on the configuration settings, Elvi reads the data from your card to start or stop a charging session. LED ring The LED ring indicates the status of Elvi.

  • Page 15: Dimensions

    3. Product features 3.2. Dimensions 3.3. Technical specifications Feature Description Electrical properties Maximum charge rate 7.2 kW (1 phase - 30 A). Charging mode Level 2 (UL2594). Fixed charging cable Type 1 plug (SAE J1772). Charging cable length 6 m (20 ft). Connection capacity 1-phase, 240 V, 30 A, 60 Hz.

  • Page 16: Delivered Components

    3. Product features Feature Description Safety Class Safety Class I and overvoltage Category III. Replaceable fuse 250 V, 2 A, fast, 5 x 20 mm, ceramic. Connectivity Authorization RFID reader (Mifrare 13.56 MHz). Communication standard Wi-Fi 2.4/5 GHz and Bluetooth 4.0 (Hub only). Cellular communication * 4G LTE / 2G GSM (Hub only).
  • Page 17 3. Product features Components in the kit Installation kit for wall dock. 1.3 Torx bit T20. 1.1 Torx screws T25 5 x 70 mm (13/64 x 2 3/4 in). 1.4 Torx bit T25. 1.2 Wall plugs 8 mm x 65 mm (5/16 x 2 9/16 in). 1.5 Torx bit T30.

  • Page 18: Installation Instructions

    4. INSTALLATION INSTRUCTIONS 4. INSTALLATION INSTRUCTIONS DANGER: Risk of electric shock. • Read and obey the safety precautions at the beginning of this manual before you install, service or use this charging station. • Switch off all power at the power supply cabinet. Secure the power supply cabinet and put up warning signs to prevent accidental supply of power.

  • Page 19: Tools And Material Required

    Wire stripper (power cable). Note: * Wood screws are required when Elvi is installed on a wood or panel wall. Only use pan head screws with a head diameter of between 8 and 10 mm (5/16 and 25/64 in). Do not use countersunk screws.

  • Page 20: Using Wi-Fi (Hub Only)

    4. INSTALLATION INSTRUCTIONS • There must be enough cable for it to extend at least 500 mm (20 in) above the cable connection point of the charging station. • The bend radius tolerance must not be exceeded. The cable enters the charging station from below. The maximum power rating for a single charging station is specified below.

  • Page 21: Hub-Satellite Installations (Optional)

    Obstructions such as walls and floors can decrease the strength of the communication signal. • If the Satellite is not within range of the Hub, or if the signal strength is too low, then the Satellite will not appear in the EVBox Connect app. 4.2. Unpacking See the corresponding illustrations in manual B.

  • Page 22: Install The Wall Dock

    4. INSTALLATION INSTRUCTIONS Push the two unlock tools, slot first, fully upwards into the holes on the bottom of the station until you hear a click. With both hands, pull the station from the wall dock in a straight line to disengage the station electrical connector from the wall dock.
  • Page 23 4. INSTALLATION INSTRUCTIONS For the optional Smart Charging network cable (Hub only), use a hole cutting bit or a flat- blade screwdriver to remove the small conduit fitting knock-out from the conduit support. Install the conduit fittings for the power supply cable and optional Smart Charging network cable.

  • Page 24: Install The Station

    Make sure that there is no gap between the station and the wall dock. 4.5. Commissioning You can configure the operation of Elvi using the EVBox Connect app. Charging stations can be connected to a Charging Management Platform (CMP) or they can be configured as not-connected installations.

  • Page 25: Pairing

    2. Open the EVBox Connect app on your smartphone or tablet, then select START PAIRING in the app. 3. Select the Chargepoint ID of Elvi, then select PAIR. The LED ring on Elvi flashes purple during pairing (Bluetooth is active).

  • Page 26: Configure The User Settings

    4. Select Set Charger to Online to be online or offline. For a charging station set to offline: • The charging cards and key fobs which are added to the EVBox Connect app are used to start and stop a charge session. For a charging station set to online: •...

  • Page 27: Configure A Hub-Satellite Installation

    RF communication is now activated and the Satellite charging stations are ready to pair. 3. Make sure that your smartphone or tablet is paired with the Hub charging station. 4. In the EVBox Connect app, select Installer mode and then enter the Security code. 5. Select Pair RF satellites then select PAIRING MODE.

  • Page 28: Operating Instructions

    5. OPERATING INSTRUCTIONS 5. OPERATING INSTRUCTIONS DANGER: Risk of electric shock. • Read and obey the safety precautions at the beginning of this manual before you use this charging station. 5.1. Charge with the charging station 5.1.1. Start and stop a charging session 1.
  • Page 29 Check the Hub-Satellite pairing. See Configure a disconnected from the Hub-Satellite installation on page Hub charging station. The Hub charging station is in Bluetooth pairing mode and Pairing on page LED ring flashing ready to pair with the purple. EVBox Connect app.

  • Page 30: Troubleshooting

    The charging station is in idle mode and the LED ring idle state Use the EVBox Connect app to set the LED is set to off or timer. (The LED ring idle state to on or timer. The LED ring ring comes on when the will stay on continuously.
  • Page 31 Check that the charge card is registered (check by user). • Check the settings of the charging station in the EVBox Connect app, and the Charging Management Platform app if available. For more information, Red LED starts contact your operator or service flashing provider.

  • Page 32: Maintenance Instructions

    Have Elvi and its installation inspected by a qualified electrician on a regular basis and in compliance with installation regulations applicable in your country.

  • Page 33: Replace The Charging Cable

    6. MAINTENANCE INSTRUCTIONS 6.2.2. Replace the charging cable See the corresponding illustrations in manual B. Note: When working on the station, place the station on a soft surface to protect it from damage. Be careful not to damage the locking tabs on the station. 1.

  • Page 34: Decommissioning

    7. DECOMMISSIONING 7. DECOMMISSIONING Remove and dispose of the charging station in accordance with applicable local disposal regulations. DANGER: Risk of electric shock. • Read and obey the safety precautions at the beginning of this manual before you install, service or use this charging station. •...

  • Page 35: Appendix

    The present document is drawn up by way of information only and does not constitute an offer binding upon EVBox ("EVBox"). EVBox has compiled the contents of this document to the best of its knowledge. No express or implied warranty is given for the completeness, accuracy, reliability or fitness for particular purpose of its content and the products and services presented therein.
  • Page 36 8. Appendix...
  • Page 37 I'm all set! Let's charge.
  • Page 38 EVBIM_022021 © EVBox Manufacturing B.V.
