4. Planning and site
preparation
4.1 General
The first step is to determine the complete monitoring solution. This consists of listing all the
loads that need to be measured, their properties, and the required hardware.
The checklist provided helps you to determine all necessary technical information for the next
steps and also to collect all the necessary hardware.
No
Solar
Yes
Note: If the requirements are not met, a custom package is required.
4.2 General architecture (what is to be monitored)
Single or multiple metering locations: Where are the circuit breakers or appliances to
be monitored? (Location inside the building, distances between them, etc.).
Total load (main service): yes/no?
Specific appliances? (e.g. HVAC, Heat pump, EV, Solar, etc.). Are they on separate
circuit breakers or are they powered from a wall socket?
Circuits (main sockets, lighting area, etc.).
4.3 Details
System: Verify the mains voltage – single phase (1P), three-phase 3P+N (3*400) or 3P
(3*230)
Grid – 1 Phase
(1P+N)
Grid – 3 Phase
(3P+N)
Grid – 1 Phase EVBox Smart Charging +
(1P+N)
Grid – 3 Phase EVBox Smart Charging +
(3P+N)
EVBox Smart Charging
1 Phase Edition
EVBox Smart Charging
3 Phase Edition
1 Phase Solar Edition
3 Phase Solar Edition
Requirements
• Wi-Fi (2.4 GHz)
• Øwire < 10 mm
• Wi-Fi (2.4 GHz)
• Øwire < 7 mm
• Wi-Fi (2.4 GHz) or Ethernet
• Øwire < 10 mm
• Wi-Fi (2.4 GHz) or Ethernet
• Øwire < 7 mm
11
