Tilting
spreader bar
Accessory for Luna
IPx4
User manual
Important information
Please read this user manual
carefully before using the product!
This user manual is intended as a
guide for caregivers and other
users,
as
well
as
technical
personnel during servicing and
maintenance of the product.
Date: 06-03-2018
Scan the QR code for more information
Version: 3
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Winncare IPx4
Summary of Contents for Winncare IPx4
- Page 1 Tilting spreader bar Accessory for Luna IPx4 User manual Important information Please read this user manual carefully before using the product! This user manual is intended as a guide for caregivers and other users, well technical personnel during servicing and maintenance of the product.
-
Page 3: Table Of Contents
CONTENTS PURPOSE AND SAFETY ________________________________________ 4 Purpose _____________________________________________ 4 Safety instructions ____________________________________ 4 Before use ___________________________________________ 4 Terminology _________________________________________ 5 Unpacking ___________________________________________ 5 Transport ___________________________________________ 5 INSTALLATION AND OPERATION _______________________________ 6 Mounting of the DPS __________________________________ 6 Operating the DPS ____________________________________ 6 USING THE DPS ______________________________________________ 7 Compatible slings _____________________________________ 7 Bed to chair__________________________________________ 7... -
Page 4: Purpose And Safety
1 PURPOSE AND SAFETY The tilting spreader bar is an add-on for the Luna IPx4 2 channel model. The tilting spreader bar works as a dynamic positioning system (DPS) and will be referred to as DPS in this user guide. -
Page 5: Terminology
1.5 Unpacking Check that all the parts are present and undamaged. Any suspicion of damage or shortage should be reported to your dealer or Winncare Nordic. We recommend that the packing carton is stored for later transport or return shipment. -
Page 6: Installation And Operation
2 INSTALLATION AND OPERATION 2.1 Mounting of the DPS Mounting the DPS The DPS is mounted the same way as other Winncare Nordic spreader bar models with strap. Lift the spreader bar. Hold the strap and depress the safety spring-plate on the hook. -
Page 7: Using The Dps
DPS. Make sure all 4 clip fixings are mounted correctly on the attachment points before carrying out a lift. If in doubt contact Winncare Nordic for assistance choosing the right sling. 3.2 Bed to chair When lifting a patient from a bed the DPS should be positioned in the lying position. -
Page 8: Maintenance
Overall condition Cracks, wear and tear, etc. If it is necessary to replace any parts due to wear or damage, Winncare Nordic recommends for safety reasons to use only original spare parts. Use of non-original spare parts will void the warranty. -
Page 9: Troubleshooting
Defective hand control. Check if up/down buttons on the hand control works. If not try a different hand control or order a new from the dealer or Winncare Nordic. Defective Luna Check the chapter “troubleshooting” in the Luna user manual. -
Page 10: Dimensions
6.2 Dimensions Measurements Lying position Sitting position (All dimensions in mm) Height Width Track to sling attachment 1070 point... -
Page 11: Environment And Quality
7.2 Quality Winncare Nordic is certified according to the quality standard ISO 9001 and ISO 13485. These certifications mean that the products and the company comply with the international standards for quality management and standards for traceability of medical products. - Page 12 Manufacturer: Winncare Nordic ApS Phone: + 45 70 27 37 20 93/42/EØF CLASS I Taarnborgvej 12 C Fax: + 45 70 27 37 19 EN/ISO 10535 4220 Korsoer E-mail: info@Winncare.dk EN 60601-1-2 Denmark www.Winncare.dk 910-00786UK...
