Biotage TurboVap 96 Dual Quick Start Manual

TurboVap 96 Dual Quick Start Guide
®
Set Up and Perform a Run (Manual and Time Mode)
For instructions regarding Method mode, see the quick start
guide Set up a Method. For instructions regarding System
Maintenance, see the quick start guide System Maintenance.
For detailed instructions, see the TurboVap
Manual. Patent pending.
Mode View
The display shows the modes available on TurboVap
1 Mode Mode selection. Press to select mode.
2
Off The corresponding side is turned off
3 Manual mode Evaporate until the user presses the Stop
button
4 Time mode Evaporate for a set period of time
5 Method mode There are several options
6 Split to left and right The left and right sides operate the same
evaporation run
7 Cancel Mode selection is cancelled
Manual Mode View
The display shows Manual Mode View. The left side is ready to
start and the right side is running an evaporation.
8
9
11
Patent Pending
© Biotage 2021
96 Dual User
®
96 Dual.
®
1
2
3
4
5
6
7
10
12
13 14
8 Manifold setup
9
Gas flow
10 Gas temperature
11 Plate temperature The current and set plate temperature in
12 Plate height
13 Start
14
Pause
15 Stop
16 System settings
* The temperature unit can be changed in the common settings.
Change a Setting
1. Press the button for the setting you want to change.
2. Press the Up and Down arrows in the appearing dialog
to change the setting step by step. Alternatively, use the
numeric keypad to enter numbers.
Time Mode View
The display shows Time Mode View. The left side is ready to
start and the right side is running an evaporation.
16
17
Time
18
Progress bar
15
TurboVap 96 Dual Quick Start Guide | Page 1
®
The selected/installed manifold
The current and set gas flow in L/min
The current and set gas temperature in
°C or °F *
°C or °F *
The current and set plate height in mm.
Press to move the plate up or down.
Press to start the evaporation
Press to pause the evaporation
Press to stop the evaporation
Press to define system settings. Displays
the system settings screen.
18
17
The set evaporation time in minutes. Press the
button to change the evaporation time.
The progress bar shows remaining and/or
elapsed time of the current evaporation.
