Displays2go FGAHSCBDK Assembly Instructions

Scan QR code to
visit product page
Pictured: Front of unit
CAM LOCKING DETAIL & SEQUENCE
1
C
x2
This step creates two compartments for back
of unit.
Ref. Qty.
A
B1
B2
C
D
E
F
TIGHTEN
Join Panels
D
Hand Sanitizer Unit with Chalkboard
Chalkboard Assembly Instructions
SKUs: FGAHSCBDK, FGAHSCBLT

Contents

Description
1 Billboard Panel
1 Left Side Panel
1 Right Side Panel
Horizontal Shelf Panel
2
Bottom Shelf Panel
2
Bottom Panel
1
1 Base
NOTE: Phillips Head screwdriver required for assembly.
Step A
Step B
Insert Cam
NOTE: Cams will be used to assemble
components in steps 1-3.
2
B1
Description
Ref. Qty.
Cam Lock
H1 30
Cam Post
H2 30
Caster with Brake
H3 2
Caster without Brake
H4 2
Caster Screw
H5 16
Bolt
H6 4
Step C
Tighten Cam
B2
E
Ver. 06.21
1 of 2
