HikRobot SC3000 Series Quick Start Manual page 13

No. Signal
15 MDI1+
16 DI_0
17 DI_1
Note
● You should refer to the table above and the label attached to the power and I/O cable to wire the
device.
● It is recommended to use the supplied 17-pin cable. The 6th, 7th, 14th, and 15th pin have been
made as RJ45 connector. The lines of other pins should be wired according to the actual demands.
SC3000 Series Vision Sensor Quick Start Guide
I/O Signal Source
--
Line 0 signal line
Line 1 signal line
Description
Fast Ethernet signal MDI1+
Opto-isolated input
Opto-isolated input
5
Cable Color
Orange
Gray
White
