Chapter 3 17-Pin Interface - HikRobot SC3000 Series Quick Start Manual

Read the following section to get definitions of 17-pin interface.
No. Signal
1 POWER_IN
2 I/O_1
3 DO_2
4 RS232TX
5 RS232RX
6 MDI0+
7 MDI1-
8 DO_0
9 I/O_0
10 DO_1
11 GND
12 IN_COM
13 I/O_2
14 MDI0-
SC3000 Series Vision Sensor Quick Start Guide

Chapter 3 17-Pin Interface

Figure 3-1 17-Pin Interface
Table 3-1 Pin Definitions
I/O Signal Source
--
Line 3 signal line
Line 7 signal line
--
--
--
--
Line 5 signal line
Line 2 signal line
Line 6 signal line
Signal ground
Line 2/3/4 input
signal ground
Line 4 signal line
--
Description
Direct current power supply positive
Can be configured as input or output
Opto-isolated output
RS232 serial port output
RS232 serial port input
Fast Ethernet signal MDI0+
Fast Ethernet signal MDI1-
Opto-isolated output
Can be configured as input or output
Opto-isolated output
Direct current power supply negative
Input signal ground
Can be configured as input or output
Fast Ethernet signal MDI0-
4
Cable Color
Red
Brown
Purple/white
Green
Green/white
Yellow
Orange/white
Blue/white
Blue
Brown/white
Black
Pink
Purple
Yellow/white
