Chapter 2 Appearance - HikRobot SC3000 Series Quick Start Manual

Note
Appearance here is for reference only. Refer to the device's specification for detailed dimension
information.
No. Name
1 17-Pin Interface
SC3000 Series Vision Sensor Quick Start Guide

Chapter 2 Appearance

Figure 2-1 Appearance
Table 2-1 Appearance Description
It provides power, input/output, Ethernet, and serial port signal. The
interface is designed with screw threads to tighten connection
between the device and cable, and thus avoiding influence caused by
vibration.
