No.
Name
2
OK/NG Indicator
3
Lens Cap
4
Light Source
5
Screw
6
Screw Hole
7
PWR Indicator
8
STS Indicator
9
LNK Indicator
10
Button
SC3000 Series Vision Sensor Quick Start Guide
It indicates the result of projects.
● The indicators are green when the project result is OK.
● The indicators are red when the project result is NG.
● The indicators are green and red when switching projects. After
switching, the indicators are unlit.
● The indicators are yellow when the device restarts or error occurs.
It can be replaced with other lens cap. Refer to the device's
specification for details.
It refers to LED lamps providing light source.
Note
The default color of LED lamps is white. Red/blue/near-infrared is
optional.
It refers to the screw between device body and lens cap.
It is used to fix the device to the installation position. You should use
M4 screw.
It is the power indicator. The indicator is green when the device
operates normally. Otherwise, it is red.
It is the status indicator. The indicator is green when the project
operates normally. Otherwise, it is red.
It is network status indicator. The indicator is flashing green when
the network transmission is normal. Otherwise, it is unlit.
It is used to trigger device to acquire images or switch projects.
Description
3
