TOWER UNIT
600 Double Appliances Inc Dr + Drw Assembly Guide
2070 x 600
2250 x 600 Tall
600 + 450 Appliance
600 + 450 Appliance
For Internal Use: FI.WR.INS.043_WKIN00143_TOWER_600_2AppIncDr+Drw.Rev7

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vogue 600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wren Kitchens Vogue 600

  • Page 1 TOWER UNIT 600 Double Appliances Inc Dr + Drw Assembly Guide 2070 x 600 2250 x 600 Tall 600 + 450 Appliance 600 + 450 Appliance For Internal Use: FI.WR.INS.043_WKIN00143_TOWER_600_2AppIncDr+Drw.Rev7...
  • Page 2: Before You Start

    TOWER UNIT 600 Double Appliances Inc Dr + Drw Assembly Guide BEFORE YOU START INSTALLATION SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Deep Drawer (Packed Separately) Fitting Pack Contents METAL BACK PANEL (Y) x2 (J) x16 (L) x2...
  • Page 3 Step 1. Secure drawer base to drawer side using 4 x 16mm drawer runner screws (J) in holes provided. Drawer base Seat the edge of drawer base tight white decorative Metal face up into corner of casing, as shown. back panel The decorative face of drawer base Drawer...
  • Page 4 TOWER UNIT 600 Double Appliances Inc Dr + Drw Assembly Guide BEFORE YOU START INSTALLATION SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel A Panel B Panel C Panel E Appliance Shelf Legs Frontal x2 Back Panel...
  • Page 5 Step 1. To attach drawer runner screw into end panels (B) using 2 x 16mm screws (J) per drawer runner, into pilot holes provided, 3rd hole from front, as shown. Drawer runner bracket screw position Step 2. Attach hinge plates onto end panels (B) to suit as shown using 2 screws already in hinge plates.
  • Page 6 TOWER UNIT 600 Double Appliances Inc Dr + Drw Assembly Guide Step 1. To attach drawer runner screw into end panels (B) using 2 x 16mm screws (J) per drawer runner, into pilot Drawer runner bracket screw position holes provided, 3rd hole from front, as shown. Step 2.
  • Page 7 Step 3. Seat dowel (F) into holes in Seat (G) both end panels (B) as shown. cam dowel into hole as shown. Step 4. Step 5. Seat cam dowel (G) into holes in both end panels (B) Attach Panels (C) & (E) to panels (B), using as shown.
  • Page 8 TOWER UNIT 600 Double Appliances Inc Dr + Drw Assembly Guide Step 7. Cut back panel (A) to suit appliance option, leaving the centre appliance aperture open. Step 8. Slide back panel (A) into groove of end panels (B). Once back panel (A) is in position, ensure the panel is flush &...
  • Page 9 Step 11. Front Position legs as shown. Ensure legs are rotated to also provide support to the end panels (B). Step 12. Secure each of the legs into place with 4 x 15mm screws (L) per leg. Front Leg position diagram Step 13.
  • Page 10 TOWER UNIT 600 Double Appliances Inc Dr + Drw Assembly Guide Screws for attaching to walls are not provided as these vary depending on materials, thickness and construction. Ensure appropriate fixings for wall construction are used. Screw into any side units using the 30mm screws (K) provided to secure to unit.
  • Page 11 Step 12. Insert hinge in top & bottom holes as shown below. Step 13. Secure hinges by tightening 2 x screws with hinge dowels attached. These are already positioned within the hinges. Step 14. Attach the door to unit where required. To attach door, clip hinge onto hinge plate and click to secure.
