3+3 drawer chest

Advertisement

Quick Links

Camden - 3+3 Drawer Chest
Assembly Instructions -
Dimensions
Width - 120cm
Depth - 39cm
Height - 65.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
305/0710
305/0703
184/3596
MADE IN
BRITAIN
Issue 4 - 12/12/13

Advertisement

loading
Need help?

Need help?

Do you have a question about the Camden 305/0710 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Camden 305/0710

  • Page 1 Camden - 3+3 Drawer Chest Assembly Instructions - 305/0710 Please keep for future reference 305/0703 184/3596 Dimensions Width - 120cm Depth - 39cm MADE IN Height - 65.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 4 - 12/12/13...
  • Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 34kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side Divider (D1996A) (D1997A) (D1999A) (620 x 389mm) (620 x 389mm) (524 x 368mm) Left Drawer Front...
  • Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer fronts Screw 2 metal dowels into the left drawer fronts and right drawer fronts Note: Tighten the metal dowels up fully against the panels.
  • Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the left drawer front and right drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the...
  • Page 7 Assembly Instructions Step 7 Fit the wedgefixes Turn the 6 drawer assemblies over and fit 4 wedgefixes to each one. Slide 2 wedgefixes into the small groove located on the back of the drawer front and 2 wedgefixes into the groove in the drawer back Once in place, tighten up the screws in the...
  • Page 8 Assembly Instructions Step 9 screw screw screw Prepare the left side Fit 3 runners the left side The 1st screw uses the 2nd hole in from the front of the runner The 2nd and 3rd screw use the holes that line up with the other panel holes.
  • Page 9 Assembly Instructions Step 10 Prepare the right side Fit 3 runners the right side The 1st screw uses the 2nd hole in from the front of the runner screw screw screw The 2nd and 3rd screw use the holes that line up with the other panel holes.
  • Page 10 Assembly Instructions Step 11 Prepare the top Screw 4 small metal dowels into the top Screw 2 metal dowels into the top Note: Tighten metal dowels up fully against Finished the panels. front edge Fix the bracket flush to the back edge of the , 300mm in from either side, using screw Step 12...
  • Page 11 Assembly Instructions Step 13 screw screw screw Prepare the divider Fit 3 runners the divider The 1st screw uses Finished the 2nd hole in from the front edge front of the runner The 2nd and 3rd screw use the holes that line up with the other panel holes.
  • Page 12 Assembly Instructions Step 14 Fit the divider Push the divider onto the top Use a screwdriver to tighten the 2 large locking nuts fitted to the divider Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
  • Page 13 Assembly Instructions Step 16 Fit the plinths to the right side 2 people are needed here One at a time, attach each of the plinths onto the right side shown. Use a screwdriver to tighten the 2 large locking nuts fitted p l a to the 2...
  • Page 14 Assembly Instructions Step 17 Fit the left side 2 people are needed here Push the left side onto the assembly. Note: You will need to slide the 2 small metal dowels fitted to the into the top of the 2 hollow core locking nuts Insert a screwdriver into the 2 hollow core locking...
  • Page 15 Assembly Instructions Step 18 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
  • Page 16 Lift with care. Panel Drawer If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2834...

This manual is also suitable for:

Camden 305/0703Camden 184/3596
