Maintenance
Battery replacement for version
with side removal
DANGER
Before changing the battery, park the truck. Ensure
that the truck is on a level surface and cannot move
accidentally.
Ensure that the unlocked battery cannot slide off and
fall onto the ground. Risk of crushing hands and feet!
– Turn off the truck and perform preliminary
maintenance operations.
– Raise the battery compartment cover.
– Disconnect the outlet from the battery plug
– Remove the rubber battery retainers.
– Place the manufacturer-approved battery
side-removal roller unit next to the truck; po-
sition it so that it is still and stable; adjust
the height of the roller unit so that it is level
with the underside of the battery at the bat-
tery compartment.
– Open the latch of the battery retainer to un-
lock it.
DANGER
"Risk of crushing hands!" The battery must be re-
moved by a single operator only. The operator
must follow the operating instructions given in this
section, positioning himself on the same side as the
battery side-removal roller unit.
– Pull the battery outwards, sliding it along
the rollers on the truck frame and position-
ing it on the previously prepared external
roller unit. Close the roller unit battery re-
tainer.
DANGER
Use a crane of suitable lifting capacity to lift the bat-
tery. Lifting operations must be performed by quali-
fied personnel. DO NOT stand within the crane's
radius of action or near the truck. Securely attach
the battery using NON-METALLIC slings. Make
sure that the lifting capacity of the slings is suitable
for the weight of the battery.
