Coemar Panorama Cyc 1800 Architectural Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
instruction
manual
1
st
edition, october 1999

Advertisement

Table of Contents
loading

Related Manuals for Coemar Panorama Cyc 1800 Architectural

Summary of Contents for Coemar Panorama Cyc 1800 Architectural

  • Page 1 instruction manual edition, october 1999...
  • Page 2 Please note in the space provided above the relative service information of the model and the retailer from whom you purchased your Panorama Cyc 1800 Architectural : This information will assist us in providing spare parts, repairs or in answering any technical enquiries with the utmost speed and accuracy.
  • Page 3 English Index 1. Packaging 2. Transporting 3. Important safety information 4. Lamp: installation and replacement 5. Operating frequency and voltage 5.1 Selecting the operating voltage and frequency of the lamp 5.2 Selecting the operating voltage of the transformer 6. Installing the unit 6.1 Installing the unit in weather-protected areas 6.2 Installing the unit in exposed areas 6.3 Installing the ballast...
  • Page 4 English Congratulations on having purchased a coemar product. You have assured yourself of a fixture of the highest quality, both in componentry and in the technology used. We renew our invitation to you to complete the service information on the previous page, to expedite any request for service information or spares (in case of problems encountered either during, or subsequent to, installation).
  • Page 5 3. Important safety information Fire prevention: 1. Panorama Cyc 1800 Architectural utilises a Philips MSI 1800; the use of any other lamp may damage the unit and will automatically void the warranty. 2. Never install the unit on flammable surfaces.
  • Page 6 English 4. Lamp: installation and replacement Panorama Cyc 1800 Architectural utilises a Philips 1800 MSI 1800W lamp with a SFc 15,5 lampbase. The lamp is available from your authorised coemar sales agent: coemar cod. 105808 power 1800 w luminous flux...
  • Page 7 English 4) Locate the SFc 15,5 lampholder. 5) The SFc 15,5 lampholder is symmetrical in its construction. The lamp used is manufactured from quartz glass and should be handled with care; always adhere to the instructions supplied in the lamp’s packaging. Never touch the glass directly, use the tissue provided in the lamp’s packaging.
  • Page 8 English 5. Operating voltage and frequency The projector may operate at 208, 230 or 240 V.at 50 or 60 Hz. c o e m a r factory presets (barring specific requests), a voltage of 240v and a frequency of 50Hz. The operating voltage and frequency of the unit is noted in the appropriate space on the label affixed to the base of the projector (electronics voltage) and internally on the ballast (lamp voltage and frequency).
  • Page 9 English 5.2 Selecting the operating voltage of the transformer This procedure will set the operating voltage for the projectors electronics. You must set the operating voltage to suit the country in which the projector is being used. Using a Philips head screwdriver, remove the 12 screws which affix the two housings of the base, these screws are located at the front, rear, and sides of the projector.

  • Page 10: Installing The Unit

    English 6. Installing the unit Panorama Cyc 1800 Architectural, due to its high protection rating, may be mounted in any position either sheltered from or exposed to the elements. 6.1 Installing the unit in weather-protected areas Panorama Cyc 1800 Touring may be situated in any mounting position when operated in sheltered areas.
  • Page 11 150mm safety chain The use of a safety chain (cod. 069) - fixed to the Panorama Cyc 1800 Architectural and to the primary suspension point, is highly recommended to protect against accidental failure, however unlikely, of the primary suspension point.

  • Page 12: Mains Connection

    7.1 Preparing mains cable The mains cable used to power up the Panorama Cyc 1800 Architectural should be 2 core + earth with conductor dimension Ø 2,5 mm and should be connected to the ballast.
  • Page 13 2) Locate the terminal strip marked L, N and GND. 3) Insert the 3 core X 2,5 mains cable into the PG 13,5 connector and cable clamp. Connect as in the diagram: 4) The cable clamp should be firmly tightened to ensure it seals against water. 5) Do not close/seal up the ballast until you have completed the following procedure.
  • Page 14 English 7.5 Mains connection Note that the Panorama Cyc 1800 Architectural may function at 208V-230V-240V at 50 or 60Hz (the voltage and fre- quency are selected as described in section 5 of this manual). Before powering up the projector, therefore, ensure that the projector you are using matches both your request and the voltage and frequency in use.

  • Page 15: Automated Operation

    The external sheath used should be selected according to the conditions in which the projector is installed and the and in accordance with local electrical authority regulatory norms. Your coemar service centre has available suitable cable: CV 2325 with properties which are suitable for installation in expo- sed conditions and non-flammable.
  • Page 16 We recommend that the PG 9 entry socket on the final projector being connected should be sealed as previously described. This will ensure the integrity of the Panorama Cyc 1800 Architectural’s weather protection rating. We recommend that this be done using a short length of unconnected signal cable being inserted into the socket and then the socket being tightened.
  • Page 17 SLAVE. The Panorama Cyc 1800 Architectural which is to act as master should be selected according to ease of access for pro- gramming purposes. Control signal is transmitted from Master to slave via 2 core ø0,5 screened cable.
  • Page 18 After having followed the preceding steps, turn on the power to the projector. Note that if you have chosen to operate the Panorama Cyc 1800 Architectural from a DMX 512 controller, you will need to turn it on prior to the projector.

  • Page 19: Dmx Addressing

    English 10. DMX addressing Each Panorama Cyc 1800 Architectural utilises 5 channels of DMX 512 signal for complete control. To ensure that each unit accesses the correct signal, it is necessary to correctly address each fixture. Any number between 1 and 506 can be generated via the multifunction panel of the Panorama Cyc 1800 Architectural.

  • Page 20: Dmx 512 Signal Functions

    English 11. DMX 512 signal functions Panorama Cyc 1800 Architectural may be operated using DMX 512 signal, connection is described in section ”8.1 Signal connection using DMX 512”. If you have followed all instructions correctly to this point, the 5 channels of your DMX 512 controller will have control of...
  • Page 21 (2 possibili selezioni) enter +o– programma n° 2 3- Adjust the hold time for each colour in the sequence, if you wish to alter from the 0 set as the coemar default. -–000 AOO1 A U S P menu + o –...
  • Page 22 (2 possibili selezioni) enter +o– programma n° 2 4- Adjust the hold time for each colour in the sequence, if you wish to alter from the 0 set as the coemar default. -–000 AOO1 A U S P menu + o –...
  • Page 23 English 13.2 Setting up “slave” units All units being operated from the master unit must be set to “Slave” mode. They must be connected correctly in the dmx daisy chain, see section 8.3 Synchronising Panoramas without DMX 512 signal Projectors set up as “Slave” are recognisable as they are the only ones with both dmx in and out sockets connected (with the exception of the last in the series which has only its “DMX IN”...

  • Page 24: Display Panel Functions

    Changing the setting made by coemar can vary the functions of the device that will not respond to the DMX 512 mixer used to control it. Please carefully follow the instructions, before applying any variations or selections.

  • Page 25: Mechanical Adjustments

    After having set up the position as required, remember to tighten the knobs once again to avoid movement. 15.2 Barndoor adjustments The Panorama Cyc 1800 Architectural features a 4 leaf barndoor which is set in the full closed position for transporta- tion.
  • Page 26 English 15.3 Altering beam angles by inserting diffusion filters The Panorama Cyc 1800 Architectural is able to offer 4 variations on the beamspread produced by the unit, thereby offering greater flexibility in its output: A) 62° on the vertical axis, 58° on the horizontal: using the standard filter B) 52°...

  • Page 27: Thermal Protection

    16. Thermal protection A thermal sensor located in the body of the Panorama Cyc 1800 Architectural protects the unit from overheating. Should the unit overheat due to it being poorly ventilated or the ambient temperature be too high or a cooling fan fail, the thermal sensor will cause voltage to be removed from the lamp circuit.
  • Page 28 English mechanicals Periodically check all mechanical devices for wear and tear; gears, guides, belts, etc., replacing them if necessary. Ensure the screws affixing the barndoors are firmly tightened. electrical components Check all electrical components for correct earthing and proper attachment of all connectors, refastening if necessary. dichroic filters To properly clean the dichroic filters it is necessary to remove the screws which affix the front block of the unit.

  • Page 29: Electronic Motor Alignment

    The display panel on the Panorama Cyc 1800 Panorama Cyc 1800 Architectural allows for the electronic calibration of the units motors; this procedure is undertaken by coemar at predelivery; it may be useful to perform this procedure in the case of internal components being replaced.

  • Page 30: Spare Parts

    English 19. Spare parts All the components of the Panorama Cyc 1800 Architectural are available as replacement spares from your authorised coemar sales agent. Accurate description of the fixture, model number, and type will assist us in providing for your requirements in an efficient...
