Coemar CF ZOOM AL Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
manuale
di istruzioni
instruction
manual
1^ edizione, gennaio 1999
st
1
edition, january 1999

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF ZOOM AL and is the answer not in the manual?

Questions and answers

Related Manuals for Coemar CF ZOOM AL

Summary of Contents for Coemar CF ZOOM AL

  • Page 1 manuale di istruzioni instruction manual 1^ edizione, gennaio 1999 edition, january 1999...
  • Page 2 Prendete nota, nello spazio apposito, dei dati relativi al modello e al rivenditore del vostro CF ZOOM AL : in caso di richiesta di informazioni, pezzi di ricambio, servizi di riparazione o altro ci permetteranno di assistervi con la massima rapidità...
  • Page 3 13. Aligning the lamp in the optical path 14 Moving the reset/home position by 90° 15. Replacing dichroic filters on the colour wheel 16. Automatic functions 17. Maintenance 18. Electronic alignment of motors 19. Spare parts Authorised coemar service centres worldwide...
  • Page 4 Congratulations on having purchased a coemar product. You have assured yourself of a fixture of the highest quality, both in componentry and in the technology used. We renew our invitation to you to complete the service information on the pre- vious page, to expedite any request for service information or spares (in case of problems encountered either during, or subse- quent to, installation).

  • Page 5: Important Safety Information

    2. For mains connection, adhere strictly to the guidelines outlined in section 7 of this manual. 3. The level of technology inherent in the CF ZOOM AL requires the use of specia- lised personnel for all service applications; refer all work to your authorised coe- mar service centre.

  • Page 6: Lamp: Installation And Replacement

    4. Lamp: Installation CF ZOOM AL utilises a Philips Fabolux 500W 55V lamp with a and replacement GX 9,5 lampbase The lamp is available from your authorised coemar sales agent: coemar cod. 105071 wattage 500 W luminous flux 11.880lm colour temperature 3200°...
  • Page 7 3) Locate the lampholder (C) 4) The GX 9,5 lampholder is symmetrical in construction; the lamp used is manufac- tured from quartz glass and should be handled with care; always adhere to the instructions supplied in the lamp’s packaging. Never touch the glass directly, use the tissue provided in the lamp’s packaging.

  • Page 8: Operating Voltage And Frequency

    5. Operating voltage and coemar factory presets (barring specific requests), a voltage of 230v and 240v frequency selectable via the switch on the base of the CF ZOOM AL. 240V 230V main setting main setting coemar: user: coemar: user: 115V...
  • Page 9 Having altered the settings as required, mark the corresponding position on the sticker located near the on/off switch as shown in the figure below: 240V main setting coemar: user: 115V 200V 208V 230V 240V Incorrect voltage selection will detrimentally affect the operation of the projector.Under no circumstance should you move the cables...

  • Page 10: Mounting The Unit

    The mounting holes in the base of the unit allow it to be mounted at various angles to the mounting truss and to trusses of various dimensions. The following is a diagram outlining the base of the CF ZOOM AL. 455mm n°...
  • Page 11 The use of a safety chain (cod. 069) - fixed to the CF ZOOM AL and to the primary suspension point, is highly recommended to protect against accidental failure, however unlikely, of the primary suspension point.

  • Page 12: Mains Connection

    - yellow/green alimentazione main protection The use of a thermal magnetic circuit breaker is recommended for each CF ZOOM AL. A good earth connection is essential for the correct operation of the fixture. Strict adherance to regulatory norms is strongly recommended.

  • Page 13: Signal Connection

    Control signal is digital, and is transmitted via two pair screened ø0.5mm cable. Connection is serial, utilising XLR 3 or XLR5 male and female sockets located on the base of the CF ZOOM AL, labeled DMX 512 and DMX 512 standard (see dia- gram).
  • Page 14 Standard DMX 512 5 pin XLR 5/F 3 pin XLR 3/M Ad altri CF ZOOM AL Connect to other CF ZOOM AL Ensure that all data conductors are isolated from one another and the metal housing of the connector. Note: the housing of the cannon XLR 3 or 5 must be isolated.
  • Page 15 After having followed the preceding steps, turn on the DMX 512 controller which will be used to control the CF ZOOM AL. Following this, turn on the power to the projector, and turn on the projector’s power switch.The projector will perform a reset function on all the internal and external motors.

  • Page 16: Dmx Addressing

    1; a projector thus addressed will respond to commands on channels 1 to 13 from the DMX 512 controller. A second projector should be addressed as 14, a third as 27 and so on until the final CF ZOOM AL has been addressed. Altering DMX addresses 1) Press the + or –...

  • Page 17: Display Panel Functions

    11. Display The display panel at the rear of the CF ZOOM AL is used to display and set panel functions function information and various parameters. Altering the coemar factory settings may vary the functioning of the projector, cau- sing it to not respond to external DMX 512 signal. Please read and familiarise your- self with the following information very carefully before altering any selections.
  • Page 18 The lamp life counter needs to be reset to zero at every lamp change to provide accurate information on lamp life 1) Turn off the projector 2) Power up the CF ZOOM AL whilst simultaneously holding down the + and – buttons. 3) Press the menu button.
  • Page 19 4) Press the + or – button; the display will show ccW (for counterclockwise). function display 5) Press the enter button after either step 3 or 4 to confirm your choice of direction. dirt This function inverts the movement for vertical (tilt) movements. 1) Press the menu button.
  • Page 20 A change in the DMX 512 signal corresponds to a colour change by the CF ZOOM AL. function display 4) Press the + or –...
  • Page 21 3) Press the enter button to confirm your selection; the display will show t 01 (for test number 1). Press the + or – buttons for subsequent tests from t 01 to t 12. function display In these tests the projector simulates the reception of a DMX 512 signal which is increasing from 1 to 255 on the selected channel.

  • Page 22: Dmx 512 Signal Functions

    If all procedures have been correctly carried out to this point, the 13 channels of functions your DMX 512 controller will have full control over all the effects available from your CF ZOOM AL as described in the following table: channel function...
  • Page 23 13. Aligning the lamp in Aligning the lamp in the optical system is achieved via the 2 adjusters at the rear lamp in the optical of the projector. system This procedure should be undertaken to properly align the lamp in the optical system and to avoid the possible overheating of the internal components due to the incorrect focusing of the beam onto components not intended to be exposed to this.
  • Page 24 1) Using a Ø 17 spanner, loosen the two bolts (A) and (B) which affix the end stop (D). 2) Without moving the yoke of the CF ZOOM AL remove the existing end stop (D). 3) Replace with the optional end stop as shown below and refasten the bolts (A).
  • Page 25 15. Replacing dichroic Dichroic filters on the colour wheel may be replaced at will; note that any filters replacements must be Ø 45mm, thickness 1.1 mm and made from tempax high temperature-resistant glass. Attention Disconnect mains power prior to attempting any replacement procedure. replacing a dichroic filter 1) Remove the inspection lid A of the projector via the two clips A as shown below.
  • Page 26 7) Insert the new colour filter by first sliding it under the central retaining clip, then sliding it back under the outer clips, ensuring that it is seated correctly in the colour wheel. 8) Replace the CF ZOOM AL inspection lid.

  • Page 27: Automatic Internal Functions

    An internal 4 point encoder system allows the CF ZOOM AL to return to its correct position in case the unit is accidentally knocked out of alignment whilst operating.

  • Page 28: Maintenance

    17. Maintenance Whilst every possible precaution has been taken to ensure the trouble-free operation of your CF ZOOM AL, the following periodic maintenance is highly recommended. Attention Disconnect mains power prior to opening the inspection lid Opening the projector: The front inspection lid allows complete access to the projector’s internals.
  • Page 29 Periodically check the lubrication of all components, par- ticularly the parts subject to high temperatures. If necessary, lubricate with suitable lubricant, available from your coemar distributor. electrical components Check all electrical components for correct earthing and proper attachment of all...

  • Page 30: Electronic Alignment Of Motors

    18. Electronic alignment The display panel at the rear of the CF ZOOM AL allows for the electronic alignment of motors of the projector’s motors. This procedure is performed by coemar at the factory. It may be useful to perform this procedure in the case of internal components being replaced.
  • Page 31 2) Press the enter button to confirm your selection; the display will show a numeri- cal value which corresponds to the factory preset. function display 3) Press the + or – button until the numerical value corresponds with the correct ali- gnment of the unit (note that with each press of the + or –...
  • Page 32 2) Press the enter button to confirm your selection; the display will show a numeri- cal value which corresponds to the factory preset. 3) Press the + or – button until the numerical value corresponds to the perfect align- ment of the yellow colour in the optical path of the projector. 4) Press the enter button to confirm your selection.

  • Page 33: Spare Parts

    19. Spare parts All the components of the CF 1200 Hard Edge are available as replacement spa- res from your authorised coemar sales agent. Accurate description of the fixture, model number, and type will assist us in provi- ding for your requirements in an efficient and effective manner.
  • Page 34 Inghilterra 46042 Castelgoffredo (Mantova) Italy Tel. 0376/77521 Fax 0376/780657 coemar si riserva il diritto di apportare modifiche senza preavviso. coemar reserves the right to effect modifications without notification manuale istruzioni instruction manual CF ZOOM AL 1^ edizione gennaio1999...
