SET COMMUNICATION:

By Pressing the "Set Communication" button from the main window for SW67C66
(Fig. 2) the window "Set Communication" appears (Fig. 3).
The means of the fields for "J1939" are:
In the field "Baudrate" the data rate of J1939 is defined;
In the field "TimeOut
received in this time, the data on EnOcean side are set to 0xFF;
If the field "Enable Peer to
Address of the J1939 messages received.
In the field "ID Device
The means of the fields for "Ethernet" are:
In the fields "IP Address" the IP address for Ethernet side of the converter is
defined;
In the fields "SubNet Mask" the SubNet Mask for Ethernet side of the converter
is defined;
In the fields "Gateway" the default gateway of the net is defined. This feature
can be enabled or disabled pressing the Check Box field. This feature is used for
going out of the net.
ADFweb.com S.r.l.
Data" a time is defined. When a J1939 message is not
Peer" is checked, the gateway will mask the Source
J1939" the ID of J1939 side of the converter is defined.
User Manual EnOcean / J1939
Document code: MN67C66_ENG Revision 1.000
Figure 3: "Set Communication" window
