SEND FRAMES:

By pressing the "Send Frames" button from the main window for SW67C66 (Fig. 2) the "Send J1939 frames" window appears (Fig. 8).
The COB inserted in this table contains the data received from EnOcean side. These frames are sent by the converter.
Figure 8: "Transmit J1939 Frames Set Access" window
The data of the columns have the following meanings:
If the field "Enable" is checked, the J1939 frame is enabled;
In the field "Cob-ID" the COB of the J1939 frame is defined;
In the field "Type" the type of J1939 packet use for this Cob-ID is defined (2.0A (11 bits) or 2.0B (29 bits));
In the field "Dimension" the number of byte of the COB (from 1 to 8) is defined;
If the field "OnChange" is checked, the frame is sent when the data from EnOcean change;
If the field "OnCMD" is checked, the frame is sent when a EnOcean message is received;
If the field "OnTimer" is checked, the frame is sent cyclically with the delay defined in the field "Time" (expressed in ms);
In the field "Byte1" insert the byte of the internal array where taking 1st byte of the J1939 message;
In the field "Byte2" insert the byte of the internal array where taking 2nd byte of the J1939 message;
In the field "Byte3" insert the byte of the internal array where taking 3rd byte of the J1939 message;
In the field "Byte4" insert the byte of the internal array where taking 4th byte of the J1939 message;
