Villa Door Station
Quick Start Guide
V1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Villa Door Station and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dahua Villa Door Station

Summary of Contents for Dahua Villa Door Station

  • Page 1 Villa Door Station Quick Start Guide V1.0.0...

  • Page 2: Foreword

    Quick Start Guide Foreword General This manual introduces the functions and operations of the villa door station and second confirmation station (hereinafter referred to as the "VTO"), and the accessory (hereinafter referred to as the "VTM"). Safety Instructions The following signal words might appear in the manual.
  • Page 3 Quick Start Guide the QR code or visit our official website. The manual is for reference only. Slight differences might be found between the electronic version and the paper version. ● All designs and software are subject to change without prior written notice. Product updates might result in some differences appearing between the actual product and the manual.
  • Page 4 Quick Start Guide Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, comply with the guidelines when using it, and keep the manual safe for future reference. Operation Requirements ●...

  • Page 5: Table Of Contents

    1.3.2 Rear Panel .......................... 7 2 Installation .............................. 8 Preparations ..........................8 Installation Guide .......................... 8 2.2.1 Villa Door Station (multiple buttons) ................... 8 2.2.2 Villa Door Station (single button) ..................9 2.2.3 Button Model ........................11 3 Web Configuration ..........................13 Initializing VTO ..........................

  • Page 6: Structure

    Quick Start Guide Structure Villa Door Station (multiple buttons) 1.1.1 Front Panel Front panel Table 1-1 Components Name Function Audio input. Provide a constant light to focus more easily on a Illuminator subject in dark surroundings. Camera Capture images or record videos for the VTO.

  • Page 7: Rear Panel

    Quick Start Guide 1.1.2 Rear Panel The function ports might differ depending on the model. Rear panel Table 1-2 Components Name Function Used to insert SD card so that data information such SD card slot as images and videos can be stored. Alarm port, door detector port, 485 port, power port Functional ports and etc.

  • Page 8: Villa Door Station (Single Button)

    Quick Start Guide Villa Door Station (single button) 1.2.1 Front Panel There are different models with different front panel. Differences in size and appearance are found depending on your model. Front panel Table 1-3 Components Name Function Audio input. Camera Capture images or record videos for the VTO.
  • Page 9 Quick Start Guide The function ports might differ depending on the model. Here are two models used as examples. Rear panel (1) Table 1-4 Components Name Function Network port Used to connect to the network. Used to insert SD card so that data information such SD card slot as images and videos can be stored.
  • Page 10 Quick Start Guide Rear panel (2) Table 1-5 Components Name Function Used to insert SD card so that data information such SD card slot as images and videos can be stored. Power port Used to connect to the power supply. Press and hold the button for several seconds to do Reset button factory reset.

  • Page 11: Button Model

    Quick Start Guide Button Model 1.3.1 Front Panel Front panel Table 1-6 Components Name Function The button model can be connected to the VTH. Press button Press the button on the model and the VTH receives an alarm signal.

  • Page 12: Rear Panel

    Quick Start Guide 1.3.2 Rear Panel Rear panel Table 1-7 Components Name Function Functional port Used for alarm input.

  • Page 13: Installation

    ● Prepare cross screwdrivers and gloves yourself. Installation Guide 2.2.1 Villa Door Station (multiple buttons) Open the port cover of the VTO, drill screw holes on the wall according to the dimension of the mounting hole on the rear panel of the VTO, and put the expansion bolts into the holes.

  • Page 14: Villa Door Station (Single Button)

    Quick Start Guide Installation 2.2.2 Villa Door Station (single button) Here are examples of two model’s installation, depending on differences in model dimensions. Model Example 1: Open the port cover of the VTO, drill screw holes on the wall according to the dimension of the mounting hole on the rear panel of the VTO.
  • Page 15 Quick Start Guide Installation Model Example 2: Open the port cover of the VTO, drill screw holes on the wall according to the dimension of the mounting hole on the rear panel of the VTO. Complete the cable wiring. Fix the port cover to the rear panel of the VTO with four screws. Fix the VTO on the wall with screws.

  • Page 16: Button Model

    Quick Start Guide Installation 2.2.3 Button Model Open the port cover of the button model, drill screw holes on the wall according to the dimension of the mounting hole on the rear panel of the button model. Complete the cable wiring. Fix the port cover to the rear panel of the button model with four screws.
  • Page 17 Quick Start Guide Installation...

  • Page 18: Web Configuration

    Quick Start Guide Web Configuration This chapter provides a step-by-step configuration of the VTO, as well as how to register digital indoor monitors (hereinafter referred to as the "VTH") into the VTO to realize its intercom function. Follow the instructions below to get started. ●...
  • Page 19 Quick Start Guide Device initialization Step 4 Select the Email checkbox and enter email address. This helps you to reset your password when your password is lost or forgotten. Figure 3-2 Set an email address Step 5 Click Next.

  • Page 20: Configuring Network Parameters

    Quick Start Guide Figure 3-3 Initialization successful Step 6 Click OK. Enter username (admin by default) and the new password to log in to the web page. Figure 3-4 Login page Configuring Network Parameters You need to configure the TCP/IP information to connect the VTO to the network. The descriptions below are for models with a Wireless LAN card.

  • Page 21: Configuring Sip Servers

    Quick Start Guide Configure the TCP/IP parameters in the LAN section. Figure 3-5 Network configuration Table 3-1 Parameter description Parameter Description IP Address Your planned IP address for the VTO. Preferred DNS The default is 8.8.8.8. Alternate DNS The default is 8.8.4.4. ...
  • Page 22 Quick Start Guide Current VTO as the SIP server If other VTOs work as the SIP server, set Server Type as VTO, and then configure the parameters. Do not enable SIP Server, otherwise the connection fails. Other VTOs as the SIP server Table 3-2 Parameter description Parameter Description...

  • Page 23: Configuring Vto Numbers

    Quick Start Guide Parameter Description Server Username/ Used to log in to the SIP server. Password Configuring VTO Numbers Numbers can be used to distinguish each VTO. In the villa scenario, we recommend you configure the VTO numbers based on your needs. Background Information ●...

  • Page 24: Adding Vtos

    Quick Start Guide Table 3-3 Parameter description Parameter Description Device Type Villa Station. Device Name The name you planned for your VTO. You could keep it null. Used to call VTHs. It should contain no more than 9 Villa Call No. numbers.
  • Page 25 Quick Start Guide Figure 3-9 VTO No. Management Step 4 Configure the parameters. Figure 3-10 Add VTOs Table 3-4 Parameters Parameter Description Rec No. VTO room number.

  • Page 26: Adding Vth Room Number

    Quick Start Guide Parameter Description Register Password Keep it by default. Build No. Keep them null when the VTO serves as the SIP server. The two parameters are only applicable when the platform works as the SIP Unit No. server. IP Address VTO IP address.
  • Page 27 Quick Start Guide Figure 3-12 Add VTH Step 4 Configure the parameters. Table 3-5 Description Parameters Description First Name Information used to differentiate each room. You can also keep them Last Name null. Nick Name The room number can contain 6 digits of numbers of letters or their combination at most, and it cannot be the same as any VTO number.

  • Page 28: Binding Vth Room Numbers (For Certain Models Only)

    Quick Start Guide Binding VTH Room Numbers (For Certain Models Only) This section only applies to the VTO model that with multiple buttons. Log in to the VTO web page. Select Local Settings > Basic. In the Façade Layout section, select Count types. Count 1: Can only bind one room number.
  • Page 29 Quick Start Guide White module Room list Click Save to save the selected room number. Click Confirm to save all the settings. Confirm...

  • Page 30: Issuing Cards

    Quick Start Guide Issuing Cards Issue an access card to unlock the door of a room. To use this function, the VTO must have a card reader. Log in to the VTO web page. Select Household Setting > Personnel Management. Figure 3-13 Personnel management Click Add.
  • Page 31 Quick Start Guide Figure 3-14 Operation succeed Select to go to the card issuing window. Figure 3-15 Card issuing window Click Issue Card to issue cards. The web page displays the countdown prompt (120 s). Once the countdown starts, you need to swipe the card on the card reader of the VTO within this time period.
  • Page 32 Quick Start Guide Figure 3-16 Countdown in process Click Confirm Send Card after swiping to complete the issuing process. Other Operations  Click to set it to loss, and then the icon changes to . The lost card cannot be used to open the door.

  • Page 33: Commissioning

    Quick Start Guide Commissioning After the basic configuration is complete, check whether the intercom communication works. VTO Calling VTH Once the VTO and VTH are connected, the duel communication function is enabled. Step 1 Dial a room number (for example, 9901) on the VTO. Step 2 to answer the call on the VTH.
  • Page 34 Quick Start Guide Figure 4-2 Door Figure 4-3 Monitoring...

  • Page 35: Cybersecurity Recommendations

    Quick Start Guide Cybersecurity Recommendations Mandatory actions to be taken for basic equipment network security: 1. Use Strong Passwords Please refer to the following suggestions to set passwords: ● The length should not be less than 8 characters. ● Include at least two types of characters; character types include upper and lower case letters, numbers and symbols.
  • Page 36 Quick Start Guide We suggest you to enable HTTPS, so that you visit Web service through a secure communication channel. 7. MAC Address Binding We recommend you to bind the IP and MAC address of the gateway to the equipment, thus reducing the risk of ARP spoofing.
  • Page 37 Quick Start Guide...
