Figure 5. Stm32H745I-Disco And Stm32H750B-Dk Discovery Board Bottom Layout - ST STM32H745I-DISCO User Manual

Figure 5.
Ethernet connector
(CN1)
MCU
(U6)
SDRAM
(U7)
Q-SPI
(U1, U2)
UM2488 - Rev 8
STM32H745I-DISCO and STM32H750B-DK Discovery board bottom layout
ARDUINO
STMod+
connector connector
(P1)
STM32H745I-DISCO and STM32H750B-DK layout
® connectors
(CN2, CN6)
STDC14
(CN14)
UM2488
USB power connector
(CN15)
STLK USB connector
(CN14)
Power header (JP8)
USB OTG FS connector
(CN13)
ARDUINO ® connectors
(CN3, CN7)
FDCANs (U21, U22)
eMMC (U11)
Line in connector (CN8)
Audio codec (U15)
Line out connector (CN9)
page 9/39
