VR-32 Regulator and CL-2A Control
1. CLAMP-TYPE TERMINALS
2. THREADED-STUD BUSHING TERMINALS
3. BUSHINGS
4. POSITlON INDICATOR
5. REGULATOR LIFTING LUGS
6. UPPER FILTER PRESS CONNECTION
7. ARRESTER MOUNTING BOSSES
8. BALL-TYPE OlL SIGHT GAUGE
9. CONTROL CABLE
10. NAMEPLATES (2)
11. GROUND BOSSES (2)
12. DRAIN VALVE & OlL SAMPLING DEVICE
13. BOLT-DOWN PROVISlONS
14. CONTROL
15. CONTROL ENCLOSURE
16. POLE-TYPE MOUNTING BRACKETS
17. ENCLOSURE SUPPORT BAR
18. HANDHOLE COVER
19. MOV-TYPE SERIES ARRESTER
20. JUNCTION BOX
21. INTERNAL ASSEMBLY LIFTING LUGS
22. PANEL-TYPE RADIATORS (Not Shown)
Figure 1-2
Features of the VR-32 Voltage Regulator.
DEFINITlONS OF ALERTS: PLEASE READ THE FOLLOWING CAREFULLY AND HEED THE WARNINGS
CAUTlONS, AND NOTICES HEREIN.
WARNING: A WARNING describes a potentially
hazardous situation which, if not avoided, could
result in death or serious injury.
NOTICE: A NOTICE describes a situation, which if
not avoided could result in damage to the equipment
with no likelihood of personal injury.
1-2
CAUTION: A CAUTION describes a potentially
hazerdous situation which, if not avoided, could
result in minor or moderate injury.
