Placement and Maintenance
CASCADIA are designed for indoor use on level floors. Clean glass with glass cleaner, and shelf with a moist cloth.
CASCADIA 8254 Cabinet
Component List
CASCADIA are engineered for easy assembly. Carefully follow this procedure to prevent any damage.
Unpack and identify the components. The assembly workspace should be a non-marring surface such as clean carpet.
For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com.
For all other concerns, please contact your BDI Retailer.
A - Hex Wrench 4mm
x 1
B - 5/16-18 x 25mm
Screws 4mm Socket Drive
x 6
D - Cabinet Assembly x 1
E - Legs x 2
F - Center Block
8254 x 1
8257 x 2
G - Back Panel
8254 x 1
8257 x 2
Designed by Matthew Weatherly
These distinctive product configurations are protected by US and international
patents, trade dress, and/or copyright laws.
BDI are trademarks of Becker Designed, Inc.
All Rights reserved. © 2011 BDI
8254 8257 Revision: 03-16-11
CASCADIA
8254 8257
C - 1/4-20 x 100mm
Screws 4mm
Socket Drive
8254 x 2
8257 x 4
BDIUSA.COM
CASCADIA 8257 Cabinet
G
B
E
1
ASSEMBLY INSTRUCTIONS
CUSTOMERSERVICE@BDIUSA.COM
D
F
C
B
E
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BDI CASCADIA 8254
Summary of Contents for BDI CASCADIA 8254
- Page 1 CASCADIA are engineered for easy assembly. Carefully follow this procedure to prevent any damage. Unpack and identify the components. The assembly workspace should be a non-marring surface such as clean carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. For all other concerns, please contact your BDI Retailer.
- Page 2 Step 1 Attach Legs to Cabinet Place Cabinet upside down on clean carpet. Using Screws (B) attach Legs (E) to Cabinet (D) and tighten with Hex Wrench (A) . Step 2 Attach Center Block to Cabinet Using Screws (C) attach Center Block (F) to Cabinet (D) bottom panel.
- Page 3 Step 3 Install Back Panel Insert top edge of Back Panel (G) into upper slot, then tilt bottom of panel in and lower panel into bottom slot. Step 4 Adjust Levelers Position Cabinet as desired then turn black puck levelers by hand to adjust as necessary. Use Hex Wrench (A) inside bottom of Cabinet to adjust center leveler as necessary.
