CV-523
HDMI 1.3 to 3G/HD/SD-SDI
Mini Converter
User Manual
Safety and Notice
The CV-523 HDMI 1.3 to 3G/HD/SD-SDI Mini Converter has been tested for conformance to safety
regulations and requirements, and has been certified for international use. However, like all electronic equipments,
the CV-523 should be used with care. Please read and follow the safety instructions to protect yourself from
possible injury and to minimize the risk of damage to the unit.
Follow all instructions and warnings marked on this unit.
Do not attempt to service this unit yourself, except where explained in this manual.
Provide proper ventilation and air circulation and do not use near water.
Keep away the objects that might damage the device and assure that the placement of this unit is on a stable
surface.
Use only the power adapter, power cords and connection cables designed for this unit.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before
cleaning.
Made in Taiwan
~ 1 ~

Advertisement

loading
Need help?

Need help?

Do you have a question about the CV-523 and is the answer not in the manual?

Questions and answers

Related Manuals for GoMax Electronics CV-523

Summary of Contents for GoMax Electronics CV-523

  • Page 1 The CV-523 HDMI 1.3 to 3G/HD/SD-SDI Mini Converter has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, the CV-523 should be used with care. Please read and follow the safety instructions to protect yourself from HDMI 1.3 to 3G/HD/SD-SDI possible injury and to minimize the risk of damage to the unit.
  • Page 2 Plus, with up to 8 channels audio support, 7.1 channel or 5.1 channel Technical audio becomes available. The CV-523 offers low jitter SDI output for daisy chain. With the use of CV-523, the SDI standards SD-SDI, HD-SDI &...
  • Page 3 Panel Description Supported Resolutions Front Panel 3G-SDI Output 1080p @ 50/ 59.94 / 60Hz SMPTE 424M, SMPTE 425M HD-SDI Output SWITCH HDMI INPUT 720p @ 50Hz SMPTE 296M -3 720p @ 60 / 59.94Hz SMPTE 296M -1, -2 1080i @ 50Hz SMPTE 274M -6 1080i @ 60 / 59.94Hz SMPTE 274M -4, -5...
  • Page 4 Limited Warranty Notice The SELLER warrants the CV-523 HDMI 1.3 to 3G/HD/SD-SDI Mini Converter to be free from defects in the Factory default: Off-Off [ - ] material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should The CV-523 supports audio sample frequency at 48kHz only.
