- Page 1 3G/HD/SD-SDI to HDMI Converter with Audio Extraction and Mixer User Manual rev: 140509 Made in Taiwan...
- Page 2 fety Noti The CV-30 05MLR HD/SD-SDI I to HDMI C Converter with Audio o Extractio on and Mix xer support has been te ested for co onformance e to safety r regulations and require ements, and d has been certified fo internationa al use.
-
Page 3: Package Contents
7.1 channel or 5.1 channel audio becomes available. The CV-305MLR also provides one low jitter SDI local loopout. With the use of CV-305MLR, the most popular uncompressed video interface in the consumer world is readily available for professional SDI... -
Page 4: Specifications
SPECIFICATIONS Model Name CV-305MLR Technical SDI standards 3G-SDI & HD-SDI & SD-SDI Auto HD/SD-SDI detection Video bandwidth [2.97Gpbs & 2.975/1.001Gbps] [3G] 1080p50/59.94/60 (4:2:2) Video support [HD] – 720p @50/59.94/60Hz,1080i@50/59.94/60Hz,1080p@24/30Hz [SD] – NTSC @59.94Hz, PAL @50Hz [SD-SDI] SMPTE 259M Input signal... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS Front Panel 1. HDMI OUT: Connect to a HDMI display with a HDMI male-male cable here. 2. Stereo Audio Output – R 3. Stereo Audio Output – L 4. S/PDIF Audio output: connect to digital S/PDIF audio speaker Rear Panel 5. -
Page 6: Connection Diagram
CONNECTION DIAGRAM... -
Page 7: Supported Resolutions
SMPTE 274M -7, -8 SD OUTPUT NTSC PAL B,D,G,H,I NOTICE 1. The CV-305MLR only embeds the audio channels in audio group 1 & 2. 2. The CV-305MLR supports audio sample frequency at 48kHz only. 3. Signal LED Indication: Green light Red light... -
Page 8: Warranty
The SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the CV-305MLR features and specifications is subject to change without further notice.
