GoMax Electronics CV-300 User Manual

Hd/sd-sdi to component converter with audio
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CV-300A
HD/SD-SDI to Component Converter
with Audio
User Manual
Made in Taiwan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV-300 and is the answer not in the manual?

Questions and answers

Related Manuals for GoMax Electronics CV-300

Summary of Contents for GoMax Electronics CV-300

  • Page 1 CV-300A HD/SD-SDI to Component Converter with Audio User Manual Made in Taiwan...

  • Page 2: Safety And Notice

    However, like all electronic equipments, CV-300 should be used with care. Please read and follow the safety instructions to protect yourself form possible injury and to minimize the risk of damage to the unit.
  • Page 3 Introduction The CV-300A HD/SD-SDI to Component Converter with Audio Support provides high quality 12 bit conversion between SDI digital video input and component analog video output. Plus, with two extra retimed SDI loop outs, CV-300A can also be treated as an advanced SDI splitter. The CV-300A supports both SD-SDI and HD-SDI formats including SMPTE 259M, SMPTE 292M, and SMPTE 296M.
  • Page 4 Specifications & Package Contents Model Name CV-300 CV-300M CV-300A Technical SDI standards SD-SDI & HD-SDI Auto HD/SD-SDI Detection Video bandwidth [1.485Gpbs & 1.485/1.001Gbps] [HD] 720p50/59.94/60, 1035i50/59.94/60, 1080i50/59.94/60, 1080p24/30 Video support [SD] NTSC@59.94Hz, PAL@50Hz Audio Support Up to 8 Channels Input signal...
  • Page 5 Power consumption 10 Watts [max] Operation temperature 0~40°C [32~104°F] Storage temperature -20~60°C [-4~140°F] Relative humidity 20~90% RH [no condensation] 1x CV-300 1x 5V power adapter 1x CV-300A 1x CV-300M 1x VGA-to-component 1x XLR Adaptor Package Contents 1x 5V power adapter...

  • Page 6: Front Panel

    Panel Descriptions Front Panel 1. 8 CH unbalanced audio outputs 4. HD/SD-SDI output #2 2. 5V power 5. HD/SD-SDI input 3. HD/SD-SDI output #1 Rear Panel 6. Component Output Pr 9. Signal Detection LED 7. Component output Pb 10. XLR output thru DSUB-24 8.

  • Page 7: Bottom Panel

    Bottom Panel A 4-pin DIP switch is used for user interface, and users can access this switch from the bottom of the unit. The following table demonstrates the functionality that users can change through different pin combinations. Pin ON ( ): Pin OFF ( ): Pin # ON ( )
  • Page 8 Limited Warranty The SELLER warrants the CV-300A HD/SD-SDI to Component Converter with Audio to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surges.

This manual is also suitable for:

Cv-300aCv-300m
