Levelflex M FMP41C with FOUNDATION Fieldbus
Endress + Hauser
10 Housing
52006205 Housing T12, aluminium, M20, PEL, cover
52013411 Housing T12, aluminium, M20, PA connector, cover
543180-1023 Housing T12, aluminium, NPT1/2, PEL
11 Hood for terminal compartment
52005643 Hood T12
12 Set of screws
535720-9020 Set of screws for housing F12/T12
20 Cover
52005936 Cover F12/T12 aluminium, inspection glass, seal
517391-0011 Cover F12/T12 aluminium, coated, seal
25 Cover for the connection compartment
518710-0020 Cover T3/T12, aluminium, coated, seal
30 Electronics
71025476 Elektronics FMP4x, Ex, PA, V4.0
31 HF module
52019780 HF module LEVELFLEX-M
35 Terminal module / power unit
52013303 Terminal module Ex d, 2-pin, 2-wire, PROFIBUS PA, Foundation Fieldbus, T12
52018950 Terminal module EEx ia, 4-pin, PROFIBUS PA, Foundation Fieldbus, T12, OVP
40 Display
52005585 Display/operating module VU331
Trouble-shooting
87
