Levelflex M FMP41C with FOUNDATION Fieldbus
Endress + Hauser
Isolated tie down
Mounting-kit
for 4mm rope probe
for 6mm rope probe
If a rope probe has to be fixed and asecure grounded moun-
ting is not possible, we recommend using the insulating
sleeve made of PEEK-GF30 with accompanying DIN 580
eye-bolt made of stainless steel.
Max. process temp.150 °C.
Due to the risk of electrostatic charge, theinsulating sleeve is
not suitable for use inhazardous areas.In these cases the
fixing must be reliably grounded (see Page 19).
Order - No.
52014249
52014250
Insulating
sleeve
D
Reliable, isolated mounting
eye-bolt
D = 20 mm at
M8 DIN 580 for 4 mm rope
D = 25 mm at
M10 DIN 580 for 6 mm rope
L00-FMP4xxxx-17-00-00-en-036
Accessories
77
