Post Base Vision
Servicedocumentation
7
Remove letter transport X16 to encoder & 2
screws at the front (
1 screw)
Lift the print assembly (use the Stylus!) and
moove it to ~1cm ( 0,4")before 1
sensor (LED)
img_3889_
Extension of the print unit:
8
Unplug X35 / flat cable
img_3891_
img_3894_
j.tolksdorf@francotyp.com
vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24
possibly infeed plate
X44 &
st
position
if necessary, remove infeed plate with LED
board (= gate with sliding sheet metal)
img_3888_
strain relief and thread out th
unclip the
eflat cable
img_3893_
11
Page
/ 27
