- Page 1 VCC-G21V21APCL Rev.900-779-32-00 English Camera link I/F VGA B/W Camera PoCL Interface Camera VCC-G21V21APCL Product Specification & Operational Manual CIS Corporation ©2016 CIS Corporation. All rights reserved.
-
Page 2: Table Of Contents
9. Initial Settings ............................. 14 10. CCD Optical Axis Accuracy ........................15 11. Dimensions ............................16 12. Cases for Indemnity (Limited Warranty) ....................17 13. CCD Pixel Defect ..........................18 14. Product Support ..........................18 ©2016 CIS Corporation. All rights reserved. -
Page 3: Scope Of Application
VCC-G21V21APCL Rev.900-779-32-00 1. Scope of Application This is to describe VCC-G21V21APCL Power Over Camera Link B/W CCD Camera. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited. 2. Handling Precautions The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or malfunction could result in serious bodily injury or loss of human life. -
Page 4: Product Outline
Rev.900-779-32-00 3. Product Outline VCC-G21V21APCL is a high-resolution industrial B/W digital video camera module utilizing a 1/2 type PS IT CCD. 330K CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution. At Full Frame Scan Mode, entire pixels can be read out within approx. 1/60s. Interface of G21V21APCL complies with camera link standard. -
Page 5: Specification
1/12000, 1/20000, 1/50000s Trigger shutter mode Fixed trigger shutter mode Pulse width trigger shutter mode (determine the exposure time by trigger signal pulse width) Trigger pulse width shall be over 1H and less than 1/2s. ©2016 CIS Corporation. All rights reserved. - Page 6 Y, and ±Z, 6 directions. (without package) Temperature Operation guaranteed: -5℃～+45℃ Performance guaranteed: 0℃～+40℃ Operation environment RH 20～80% with no condensation Humidity Temperature -25℃ ～ +60℃ Storage environment RH 20～80% with no condensation Humidity ©2016 CIS Corporation. All rights reserved.
-
Page 7: Camera Output Signal Specification
: 020 ± 00Ch Digital 10bit 5 seconds shall be waited after turning on power to get proper camera operation. 4.3. CCD Spectral Response (Representative value) ※ Lens characteristics and illuminant characteristics are not considered. ©2016 CIS Corporation. All rights reserved. -
Page 8: Function Settings
Address 009 MSB and address 010 LSB makes 10bit_ in total. Shutter Speed = (524.6--Data) x 31.78μs Max Data = 20Ch = 524 Positive Input Trigger Polarity Negative Input No Function Fixed. Do not change. ©2016 CIS Corporation. All rights reserved. - Page 9 Re-triggering at H-Synchronous Mode shall be after 2H of CCD read out signal. Re-triggering at CLK-Synchronous Mode shall be after completion of video output. Trigger pulse width shall be within the range of over 1HD to less than 1/2 sec. ©2016 CIS Corporation. All rights reserved.
-
Page 10: External Connector Pin Assignment
6. External Connector Pin Assignment 26pins camera Link connector 12226-1100-00 PL (SUMITOMO 3M) Pin No. Pin No. DC＋12V Xclk- Xclk+ SerTC+ SerTC- SerTFG- SerTFG+ CC1- CC1+ (Trigger IN-) (Trigger IN+) CC2+ CC2- CC3- CC3+ CC4+ CC4- (GND) DC＋12V ©2016 CIS Corporation. All rights reserved. -
Page 11: Timing Chart
"L" Exposure Time Read OUT Signals Discharge Signals Video Output Scan Mode a line b line c line Total line number number number numbers Full Frame Scan Mode 14 H 494 H 525 H ©2016 CIS Corporation. All rights reserved. -
Page 12: Trigger Shutter Mode
Full Frame Scan Mode 14 H 494 H 525 H CLK- Synchronous Mode Details at Pulse Width Trigger Shutter Mode Trigger Input Signals Discharge Signals Read OUT Signals Delay Time 4.6μs Delay Time 24.0μs Exposure Time ©2016 CIS Corporation. All rights reserved. -
Page 13: Remote Interface Function
To save the data into EEPROM, please refer to Clause 5.4. Function Setting. Note: Once the data was saved into EEPROM, it may not be reset to t he initial settings. C is the code to send the data back from the camera. ©2016 CIS Corporation. All rights reserved. -
Page 14: Initial Settings
Invalid Manual White Balance R Gain Control Invalid Manual Gain Control Invalid Manual Shutter Control 009&010 Invalid Trigger Polarity 0: Positive Input Output Data Select 0:8bit Output Data Trigger Reset Mode 0: H-Synchronous Mode ©2016 CIS Corporation. All rights reserved. -
Page 15: Ccd Optical Axis Accuracy
?? ±0.5° The center of effective pixels shall be Within f 0.6 to the center of lens mount. (*) Dimensions from datum plane to the center of lens mount. 910-007-01-01 (Unit :mm) ©2016 CIS Corporation. All rights reserved. -
Page 16: Dimensions
VCC-G21V21APCL Rev.900-779-32-00 11. Dimensions ©2016 CIS Corporation. All rights reserved. -
Page 17: Cases For Indemnity (Limited Warranty)
In case damage or losses are caused by repair or modification conducted by the customer or any unauthorized third party (such as an unauthorized service representative). Expenses we bear on this product shall be limited to the individual price of the product. ©2016 CIS Corporation. All rights reserved. -
Page 18: Ccd Pixel Defect
We shall be exempted from taking responsibility and held harmless for damage or malfunction of your hardware and software caused by using this control software. The purpose of this control software is for you to check operation and evaluate our products. Please be noted that CIS does not customize the program nor provide source code.
