Knife Support Chain - MyBinding Plockmatic FTR200 Service Manual

29 November 2006

3.2.18 KNIFE SUPPORT CHAIN

1. Remove Front cover (
2. Remove Transmission chain (
3. Loosen screws [A] (
4. Remove chain from sprocket [B].
Replacement
1. Reverse the removal procedure.
2. Tension the chain so there is no slack when tightening screws [A] (
[B] [A]
3.1.1).
3.2.17).
x3).
FTR-3-31
AREA C
x3).
