COVERS

3.1.2 TOP COVER

[A]
[B]
Bad
Top cover too low
Removal
1.
Pry off the Gas spring [A] using a screw driver.
2.
Remove screws and nuts [B] (
Replacement
1.
Reverse the removal procedure.
Adjustment
1.
Loosen screws and nuts [B] (
2.
Adjust Top cover so frame edge [C] is aligned with top of the hinge [D].
See drawings above.
3.
Tighten screws and nuts [C] (
Good
Top cover too high
x4,
x4).
x4,
x4).
x4,
x4).
FTR-3-2
29 November 2006
[B]
[C]
[D]
Bad
