29 November 2006
3.1.9 PROTECTION COVER
[A]
Removal
1.
Lift out scrap paper bin [B].
2.
Remove screws [A] (
Replacement
1.
Place the front end of the cover up against the lower knife beam [C].
2.
Push in cover so it hooks onto the screws [D].
3.
Mount screws [A] (
Replacement Step 1.
Replacement Step 2.
x4).
x4).
FTR-3-9
[B]
COVERS
[C]
[D]
