29 November 2006
3.2.12 LENGTH ADJUSTMENT MOTOR M4 & SENSOR Q12
[B]
1.
Remove Stop gate carriage (
2.
Unhook spring [A].
3.
Remove screws [B] holding the motor (
[A]
3.2.10).
x4).
FTR-3-25
AREA C
