AREA C
7. Use a feeler gauge and check that the space [Q] between upper knife and the
two red marked reference screws in the middle [P] is 0.50 mm.
NOTE: Never touch the red painted reference screws [P].
8. Adjust the space if necessary with screws [O] (
9. Bring the Upper knife down to the bottom position by turning crank [R] using a
13 mm wrench.
NOTE: When bringing the Upper knife down, make sure it does not touch the
Lower knife.
10. Gently push in the Lower knife against the Upper knife.
NOTE: Listen that it touches on both sides.
11. Raise the upper knife to the top position by turning crank [R].
12. Tighten screws [I] & [H] (
NOTE: Tighten a little at first according to the sequence 1-6. Then tighten a lit-
tle harder to finally fully tighten the screws. Always according to the sequence
1-6.
13. Turn screws [M] (
[O]
[P]
[R]
x6).
x3) so they touch the lower knife.
FTR-3-20
29 November 2006
x2).
[Q]
