AREA C
3.2.2 CONTROL SWITCH S2
Removal
1.
Remove Rear cover (
2.
Remove connectors [A] (
3.
Remove screws [B] (
Replacement
1.
Reverse the removal procedure.
Adjustment
1.
Lift the Infeed shaft.
2.
Make sure the Switch activates slightly before the shaft latches in upper posi-
tion.
3.
To adjust, loosen screws [B] (
4.
Reposition switch to obtain adjustment.
5.
Tighten screws [B] (
[A]
[B]
3.1.1).
x2).
x2 ).
x2 ).
x2 ).
FTR-3-12
29 November 2006
