29 November 2006
3.2.3 CONTROL SWITCH S3
[B]
Removal
1.
Remove Rear cover (
2.
Remove connector [B] (
3.
Remove screw [A] (
Replacement
1.
Reverse the removal procedure.
Adjustment
1.
Lift the compressing bracket.
2.
Make sure the Switch activates approximately 10 mm from where the com-
pressing bracket latches in the upper position.
3.
To adjust, loosen screws [A] (
4.
Reposition switch to obtain adjustment.
5.
Tighten screws [A] (
3.1.1).
X2).
x2).
x2 ).
x2 ).
FTR-3-13
AREA C
[A]
