29 November 2006

3.2.16 TRIM BIN FULL SENSOR Q8

1.
Undock the Trimmer.
2.
Remove connector [A] (
3.
Remove screw [B] (
[B]
x1).
x1).
FTR-3-29
[A]
AREA C
