AREA C

3.2.6 TRIM KNIFE MOTOR M2

WARNING
Place the safety block [D] between lower knife and upper knife beam. When
removing the chain nothing holds upper knife beam and knife in position.
[B]
[D]
Removal
1. Remove Rear cover (
2. Remove connector [E] (
3. Remove circlip [C] using a circlip plier.
4. Loosen screws [A] holding the motor (
5. Remove sprocket [F].
6. Remove screws [A] holding the motor (
Replacement
1. If it is difficult to mount sprocket [F] remove master link [B].
2. Reverse the removal procedure.
3. Tension the chain so there is no slack when tightening screws [A] (
[A] [C] [F]
3.1.1).
x1).
x3).
x3).
FTR-3-16
29 November 2006
[E]
x3).
