- Page 1 This guideline is applicable for the Hyena e-bike system only BS-A370 Product Manual Copyright © 2020 HYENA INC. All Right Reserved. Version 1.0 This manual is intended primarily for the trained technician to install, disassemble, or maintain the e-bike.
-
Page 2: Table Of Contents
Content Product Features Product Description Parts Description Product Dimension Pin Definition Technical Data Mounting Tool List Accessory List Mounting Instructions Operation Operation Instructions Charging Instructions Safety Instructions Important Notice Grounding Instructions Moving and Storage Instructions Maintenance Product Warning Label Disposal... -
Page 3: Product Features
Product Features Product Description BS-A370 Semi in-tube battery offers a solution for customers looking to integrate the battery within the frame. Its semi in-tube design concealed the battery in the bike’s downtube, not only helps prevent damage during drops or a crash, but it also makes battery swaps easier than the complete in-frame batteries, and keep the bike outward appearance in elegance. -
Page 4: Product Dimension
Pin Definition Charge (3 pins female, connect to battery charger) Name Direction Description Remark Ground Input Ground Output Power Input Charge Discharge (2 pins female, connect to driver) Name Direction Description Remark Power Output Discharge Ground Output Ground HYENA E-BIKE SYSTEMS... - Page 5 Driver Communication (4 pins male, connect to driver) Name Direction Description Remark Bike Present Input Reserved DEN/HMI Bidirectional Active low, used to wakeup battery from sleep mode. CAN H Bidirectional CAN High CAN L Bidirectional CAN Low HYENA E-BIKE SYSTEMS...
-
Page 6: Technical Data
Percentage of recoverable capacity = 80% -20℃~+20℃ 80%RH (<12 month) Charging temperature 0℃~+45℃ 80%RH 2A charger - 5h Charging time approx. 4A charger - 2h30min Mounting Parameter In frame tube Mounting position L430, W68, H74 mm Dimension Certification EN15194:2017 UL2271 UN38.3 IEC62133 HYENA E-BIKE SYSTEMS... -
Page 7: Mounting
Battery Discharge Holder Installation Step 1: Insert the bottom plate of the holder. Step 2: Insert the side plate (non-discharge end). Step 3: Screw the side plate to the frame. Step 4: Screw the side plate to the bottom plate. HYENA E-BIKE SYSTEMS... - Page 8 Step 8: Screw the side plate and lock together. end) to the e-bike driver, then insert the side plate. Step 9: Screw the side plate to the frame. Step 10: Screw the side plate to the bottom plate. HYENA E-BIKE SYSTEMS...
- Page 9 Remove the Battery Step 1: Insert the key. Step 2: Turn the key and lift the battery from the lock end. Step 3: Take the battery out. HYENA E-BIKE SYSTEMS...
-
Page 10: Operation
The battery charger's • All Hyena Chargers only use genuine Hyena batteries power plug may come loose and not be fully inserted into and battery packs, or battery packs approved for use with the electrical outlet, resulting in a risk of fire. -
Page 11: Charging Instructions
• CAUTION - Do not place the battery charger at locations that are easily accessible to children. HYENA E-BIKE SYSTEMS... -
Page 12: Safety Instructions
• Do not bundle the charger cables. signs of damage. • Do not hold the battery charger by the cables when • All the component leads shall use original Hyena carrying it. components. • In order to prevent the cable from being damaged, avoid •... -
Page 13: Product Warning Label
• Dispose of the used battery according to local • Do not dispose of e-bikes and their components with ordinances and/or regulations. household waste. SAVE THESE INSTRUCTIONS HYENA E-BIKE SYSTEMS...
