- Page 1 Product Manual MRC-B750 Original Instruction Version 221110 Copyright © 2022 HYENA INC. All Right Reserved.
-
Page 2: Table Of Contents
Table of Contents Introduction Product Features Product Description .................. 1 Parts Description ..................1 Product Dimension ................... 2 Technical Data Function ....................3 Characteristic .................... 3 Mounting Parameter ................. 4 Certification ....................4 Mounting Tool List ....................5 Accessory List ................... 5 Mounting Instructions ................ -
Page 3: Introduction
Product Features Product Description MRC-B750 rear hub motor provides power for the e-bike with less maintenance required. It features longer OLD for fat-tire bikes, extra high torque, and acceleration for utility and heavy-load bikes. Compatible with 8-10 speed cassette sprocket. -
Page 4: Product Dimension
Product Dimension Item Dimension +0.2 18-Φ3.2 (PCD=128) Φ164.0 PCDΦ150.8 230±2 +1.5 (O.L.D.)175 +0.4 15.25 -0.2 70.75 Φ17.0 58.5 (WL) 220±10 Unit: mm HYENA E-BIKE SYSTEMS... -
Page 5: Technical Data Function
4.7 kg (10.36 lb) Waterproof level IP54 Hall sensor Speed sensor 1 Magnet Characteristic Protocol Control type Sine wave Reduction ratio Operating temperature -10℃ to +50℃ @80%RH Storage temperature -20℃ to +70℃ @80%RH ≥ 50 MΩ Insulation HYENA E-BIKE SYSTEMS... -
Page 6: Mounting Parameter
36 H Spoke hole type Brake type Disc brake BCD 44 mm 6 bolts Cassette 8-10 speed Derailleur Non-drive side through the shell Cable outlet Cable length 220±10 mm JL-FV2-Z916AG Standard connector Connection Certification EN 15194:2017 RoHS HYENA E-BIKE SYSTEMS... -
Page 7: Mounting
Hexagon nut (2 pcs) Torque washer (2 pcs) Flat washer (2 pcs) M12xP1.25xt10mm OD20XID12xW10xt4 OD22xID12xt2.5mm Plastic gasket (1 pc) Button head socket screw Nut cap (2 pcs) (attached on the motor) (6 pcs) (attached on the motor) OD56xID34xt2mm M5x7mm OD26xID18x28mm HYENA E-BIKE SYSTEMS... -
Page 8: Mounting Instructions
The bike image in the manual may be different from the actual bike, but will be enough to help you understand related instructions. Exploded View of Assembly Installation STEP STEP Install and fasten the cassette sprocket and cassette Remove the screws and plastic gasket from the locking ring (right side). motor (left side). HYENA E-BIKE SYSTEMS... - Page 9 (washer bulge aligns with the flat side of the shaft). STEP STEP Install the motor (rear wheel). Insert the flat washers and fasten the hex nuts with torque to 40 Nm then install the nut caps. STEP Completed. HYENA E-BIKE SYSTEMS...
-
Page 10: Safety Instructions
Maintenance other signs of damage. • Do NOT clean the product or any e-system component • All the component leads shall use original Hyena with detergent or organic solvent. Only clean the product components. with a water-dampened soft cloth. - Page 11 This page is intended to be blank. HYENA E-BIKE SYSTEMS...
- Page 12 Hyena Inc. Tel: +886 4 23598810 Fax: +886 4 23598610 www.hyena-ebike.com Address: No.25, Jingke N. Rd., Nantun Dist., Taichung City 408, Taiwan (R.O.C.) HYENA E-BIKE SYSTEMS...
