GOLANDER PUMP
BT-F NEW Operation Manual
For Intelligent Dispensing Peristaltic Pump

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT-F NEW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Golander pump BT-F NEW

Summary of Contents for Golander pump BT-F NEW

  • Page 1 GOLANDER PUMP BT-F NEW Operation Manual For Intelligent Dispensing Peristaltic Pump...

  • Page 2: Table Of Contents

    Contents Safety Cautions ..................1 1 Description ..................1 2 Functions and Features ..............2 3 Components and Connectors ............. 4 4 Display Panel and Operating Keypads ..........5 4.1 Keypad ..................5 4.2 LCD Touch Screen Display ............6 4.3 Status bar .................

  • Page 3: Safety Cautions

    BT-F NEW Intelligent Dispensing Peristaltic Pump Safety Cautions Danger: Please use correct AC power voltage source shown on the sticker on the equipment to avoid any damage. Please do not open the case. High voltages exist and are accessible. Use extreme caution when servicing internal components.

  • Page 4: Functions And Features

    BT-F NEW Intelligent Dispensing Peristaltic Pump • BT300F, flow rate: 0.006-1600 mL/min, speed: 0.1-350 rpm • BT600F, flow rate: 0.006-2900 mL/min, speed: 0.1-600 rpm 2 Functions and Features Advantage of peristaltic pump: Peristaltic pump can handle extremely viscous fluids, abrasive slurries and corrosive fluids. There is no seals in contact with the medium pumped and no valves to clog.
  • Page 5 BT-F NEW Intelligent Dispensing Peristaltic Pump • Internal double-deck isolation structure; circuit board with conformal coating makes it dust-proof and moisture proof. • Anti-electromagnetic interference feature, wide input voltage range for complex power environment. • Stainless steel enclosure, easy to clean, resistant to the...

  • Page 6: Components And Connectors

    BT-F NEW Intelligent Dispensing Peristaltic Pump 3 Components and Connectors Handle Driver Color LCD Touch Screen Coupler Pump Head Mounting Bracket RS232 DB15 External Control Interface Power Switch Fuse Power Connector Cooling Fan Figure 1. Components and Connectors...

  • Page 7: Display Panel And Operating Keypads

    BT-F NEW Intelligent Dispensing Peristaltic Pump 4 Display Panel and Operating Keypads LCD DISPLAY BT600F DIRECTION START/STOP PRIME MODE MODE Figure 2. Display Panel 4.1 Keypad START/STOP key. Press to start or stop pump. DIRECTION Key. Press to change the drive rotating direction, clockwise or counterclockwise.

  • Page 8: Lcd Touch Screen Display

    BT-F NEW Intelligent Dispensing Peristaltic Pump 4.2 LCD Touch Screen Display 34℃ 12:35:46 Status bar Flow Delayed Start 9.000 mL/min 00:00:00 Operation display Delayed Stop 150.0 00:00:00 Speed Navigation FLOW button Figure 3. Main screen 4.3 Status bar A. Tone Button status, the icon show the key tone on/off.
  • Page 9 BT-F NEW Intelligent Dispensing Peristaltic Pump 34℃ 12:35:46 34℃ 12:35:46 Flow Flow Delayed Start Delayed Start 00:00:00 00:00:00 9.000 9.000 uL/min uL/min Delayed Stop Delayed Stop 00:00:00 00:00:00 150.0 150.0 Speed Speed FLOW FLOW Keypad unlocked Keypad locked Figure 5 Keypad Lock C.
  • Page 10 BT-F NEW Intelligent Dispensing Peristaltic Pump 34℃ 12:35:46 Flow Delayed Start 00:00:00 9.000 uL/min Delayed Stop 00:00:00 150.0 Speed FLOW Figure 7 Footswitch Control Mode Current Control Mode: External 4-20mA analog current signal controls flow rate, external logic level signal controls start/stop.
  • Page 11 BT-F NEW Intelligent Dispensing Peristaltic Pump 34℃ 12:35:46 Flow 0V Speed 9.000 uL/min 5V Speed 600.0 150.0 Speed FLOW Figure 9 Voltage Control Mode Voltage Control Mode 0-10V: External 0-10V analog voltage signal controls flow rate. External logic level signal controls start/stop and direction.
  • Page 12 BT-F NEW Intelligent Dispensing Peristaltic Pump 12:35:46 34℃ 34℃ 12:35:46 Flow Flow Delayed Start Delayed Start 00:00:00 9.000 00:00:00 9.000 uL/min uL/min Delayed Stop Delayed Stop 00:00:00 00:00:00 150.0 150.0 Speed Speed FLOW FLOW Communication connected communication disconnected Figure 11 Communication State E.

  • Page 13: Operation Zone

    BT-F NEW Intelligent Dispensing Peristaltic Pump 34℃ 12:35:46 Head: YZ15 Tube: 流量 Flow 9.000 Speed: 150.0 rpm 毫升/分 Elapsed: 0.000 uL ul/min 00:00:00 Total: 13.980 mL 转/分 FLOW Figure 13 Running Animation G. Temperature display: display current degree of driver, such as 34 °C.

  • Page 14: Navigation Button

    BT-F NEW Intelligent Dispensing Peristaltic Pump Flow unit Setting uL/min mL/min L/min Figure 15 Choose Flow Rate Unit 6 Navigation button Mode setting - Set the specific control mode in different working modes, the prompt tone is on/off, and the lock is on/off.
  • Page 15 BT-F NEW Intelligent Dispensing Peristaltic Pump Preview mode - View running status, parameter changes. Among them, the current running parameter appears on the left side of the interface, and the running status is displayed on the right side. 34℃ 12:35:46...
  • Page 16 BT-F NEW Intelligent Dispensing Peristaltic Pump Counter clockwise operation Clockwise operation Flow Flow Flow Flow 9.000 9.000 9.000 9.000 mL/min mL/min mL/min mL/min Figure 19 Direction indication In dispense mode, orange is the stop state, green is the running state,...
  • Page 17 BT-F NEW Intelligent Dispensing Peristaltic Pump button or button shortly to increase or decrease the flow rate. Press and hold the buttons to change the value quickly. Increase key Decrease key Figure 22 Fine Adjustment Button Calibrate - Pump will accurately show current flow rate/volume by measuring the weight or volume of the transferred fluid through balance or cylinder.
  • Page 18 BT-F NEW Intelligent Dispensing Peristaltic Pump details as Figure 24. General Settings General Settings Tubing PumpHead YZ15 Tubing Anti- Drip 0° Anti- Drip 0° Irda Figure 24 General Settings interface • Pump Head: Choose the model of the installed pump head, use buttons to view the menu, as shown in Figure 25.
  • Page 19 BT-F NEW Intelligent Dispensing Peristaltic Pump Tube Settings Min Flow 6.000 uL/min Max Flow 9.000 mL/min Figure 26 Tubing Select • Anti-drip setting: The peristaltic pump will rotate the set angle reversely to prevent fluid dropping from the tubing when the peristaltic pump stops.
  • Page 20 BT-F NEW Intelligent Dispensing Peristaltic Pump • Communication settings - Sets the parameters of RS485 communication, as shown in Figure 28. Com Settings Baud(bps) 9600 PAR_EVEN Byte Order CDAB Pump No. Figure 28 Communication Settings When the password is empty, you can see more parameter settings in general settings, and use buttons to view the menu.
  • Page 21 BT-F NEW Intelligent Dispensing Peristaltic Pump • Pulse signal: When the external control signal is a pulse signal, choose the descending edge or the rising edge by the option. The descent edge is a jump from high to low level, and the rising edge is a jump from low level to high level.
  • Page 22 BT-F NEW Intelligent Dispensing Peristaltic Pump System Settings System Settings Finish Tip Date Settings 100% 2017-08-22 Time Settings Alarm block 12:34 Language Settings Factory Reset English BackLight Settings Tube Limited Reset System Settings Factory Reset Tube Limited Reset Reset WIFI...
  • Page 23 BT-F NEW Intelligent Dispensing Peristaltic Pump Time Settings Hour Minute Second Figure 34 Time setting • Language: Choose display language, Chinese or English Language CHINESE ENGLISH Figure 34 Language • Factory Reset: It is to reset the pump to factory settings. Restart pump to apply the settings.
  • Page 24 BT-F NEW Intelligent Dispensing Peristaltic Pump quantity and flow mode or liquid quantity and time mode. 1 2 3 4 5 6 7 8 Figure 36 Transmission mode Information query - For information about the using of peristaltic pump, use the page to view the peristaltic pump...

  • Page 25: External Control Interface

    BT-F NEW Intelligent Dispensing Peristaltic Pump 7 External Control Interface DB15 Mark Note ADC_W Positive of external analog input Communication interface, B pole of RS485 Communication interface, A pole of RS485 VCC_W External DC power input Analog voltage signal output...

  • Page 26: Operation Instructions

    BT-F NEW Intelligent Dispensing Peristaltic Pump Signal ground line Table 2 RS232 definition 8 Operation Instructions 8.1 Before Operation 1) Please check the packing slip to make sure nothing is wrong or damaged in the package. If there is problem, please contact the manufacturer or distributor.
  • Page 27 BT-F NEW Intelligent Dispensing Peristaltic Pump 3) Press prime key to fill tubing with liquid. 4) When pump is not running, press , or enter system settings to choose calibration wizard icon. 5) On the calibration wizard screen, system shows the calibration of current selected tubing, flow rate and fluid volume.
  • Page 28 BT-F NEW Intelligent Dispensing Peristaltic Pump volume. Repeat the above steps couple more times, and enter the results of the Test1, Test2 and test3 in the calibration window. Please pay attention to the unit to make sure it is correct, press button to enter the Calibrate Calculate screen.

  • Page 29: Working Mode

    BT-F NEW Intelligent Dispensing Peristaltic Pump Figure 41 Calibrate result If there is no data input to the system, it will show the window as below. Please press to test again or just press Return. Calibrate Analyze and Calculate,No data.
  • Page 30 BT-F NEW Intelligent Dispensing Peristaltic Pump 34℃ 12:35:46 34℃ 12:35:46 Head： YZ15 Flow Delayed Start Tube： 流量 Flow 00:00:00 9.000 uL/min 9.000 Speed： 150.0 rpm 毫升/分 Elapsed： 0.000 uL Delayed Stop ul/min 00:00:00 Total： 13.980 mL 00:00:00 150.0 Speed 转/分...
  • Page 31 BT-F NEW Intelligent Dispensing Peristaltic Pump between doses and number of cycles. System will calculate duration time for each dose automatically. 34℃ 12:35:46 34℃ 12:35:46 Head： YZ15 Flow Tube： 60.00 1.000 1.000 Speed： 150.0 rpm uL /min Elapsed： 0.000 uL 00:00:00 Total：...
  • Page 32 BT-F NEW Intelligent Dispensing Peristaltic Pump Click Mode setting icon, select different group numbers in the interface, can be stored in five groups Mode Settings Dispense NO.1 Reserved Sound Lock • Time Dispense Mode Pump will dispense by setting the dispense duration for each dose, lag time between doses and number of cycles.
  • Page 33 BT-F NEW Intelligent Dispensing Peristaltic Pump Mode setting icon, select different group numbers in the interface, can be stored in five groups CW_W ADC_W AGND RS_W 0-5V/0-10V /4-20mA • Loop dispense mode By setting the steps to run and the number of cycles, the pump automatically completes each step by following the steps.

  • Page 34: External Control Mode

    BT-F NEW Intelligent Dispensing Peristaltic Pump Clockwise or counterclockwise. The preview interface shows the current pump head tube size, the amount of fluid that has been run, the volume, time and the number of times it has been run Click...
  • Page 35 BT-F NEW Intelligent Dispensing Peristaltic Pump 3) Press the MODE key to select the flow mode 4) Select voltage mode or current mode by control mode 34℃ 12:35:46 34℃ 12:35:46 Flow 4mA Speed Flow 0V Speed 9.000 9.000 uL/min uL/min...

  • Page 36: Communication Mode

    BT-F NEW Intelligent Dispensing Peristaltic Pump CW_W 1.5K ADC_W AGND RS_W 1.5K VCC_W 0-5V/0-10V /4-20mA 24VDC Wiring Diagram of external Control Mode connecting external Figure 52 DC24V Power supply 8.6 Communication mode The RS485 interface supports standard MODBUS protocol. Pump can be controlled by external device via the communication port.
  • Page 37 BT-F NEW Intelligent Dispensing Peristaltic Pump Figure 53 Control Start/Stop with internal 12V Power Source 2) Turn the power on. Pump will display the main screen. 34℃ 12:35:46 Flow Delayed Start 9.000 uL/min 00:00:00 Delayed Stop 150.0 00:00:00 Speed FLOW...

  • Page 38: Footswitch

    BT-F NEW Intelligent Dispensing Peristaltic Pump Baud(bps) Parity Bit 4800 NONE 9600 19200 38400 Byte Order CDAB ABCD Figure 55 communication interface After the connection is successful, the functions of the pump are controlled by the communication instruction 8.7 Footswitch Power pump off.

  • Page 39: Maintenance

    BT-F NEW Intelligent Dispensing Peristaltic Pump RS_W Figure 57 Footswitch Control Start/Stop with internal 12V Power Source Turn the power on. Pump will display the main screen. On Internal Control Mode, if pump is set to Volume, Time or Cycle Dispense Mode, when the switch RS_W is closed then open, pump will start to dispense.

  • Page 40: Regular Maintenance

    BT-F NEW Intelligent Dispensing Peristaltic Pump 9.2 Regular Maintenance 1) Always check the tubing and connections to make sure there is no leakage. 2) Do not cover the fan on the rear of the pump. 3) Do not use water to wash the pump. Keep pump head dry.
  • Page 41 BT-F NEW Intelligent Dispensing Peristaltic Pump 2. Check if the key is broken. 1. Check the wiring of the connector. External 2. Check if the external control Hardware control does power voltage is provided. not work 3. Check the connections of the external control board.

  • Page 42: Dimensions

    BT-F NEW Intelligent Dispensing Peristaltic Pump 10 Dimensions Figure 59 Dimensions (mm) 11 Naming Rule Drive mode Flow Rate Rotation Speed Version Pump type Function IP rating B: Step motor Q: Micro flow rate 06: 60 rpm D: Fixed speed...

  • Page 43: Specifications

    BT-F NEW Intelligent Dispensing Peristaltic Pump 12 Specifications Speed resolution 0.1 rpm Speed accuracy 0.2% Power supply AC 100-240V 50Hz/60Hz Power consumption BT101F: < 30W; BT301F:< 40W; BT601F: < 50W Logic level control signal 5V, 12V (standard), 24V (optional) External analog control 0-5V (standard);...
  • Page 44 BT-F NEW Intelligent Dispensing Peristaltic Pump 13# 14#, DT10-28 Wall:0.8~1, 0.0002~82 ID:≤3.17 13# 14# 16# 19# YZ15 0.0006~420 25# 17# YZ25 15# 24# 0.16~420 13# 14# 16# 19# YT15 0.006~570 25# 17# 18# YT25 15# 24# 35# 36# 0.17~720 BT300F Suitable Pump Heads and Tubing, Flow Parameters Pump No.
