Directed DIRECTECHS DB3 Installation Manual page 9

Module
Conn./Pin Color
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire
12 Volts
Accessory
Hood Pin
Ignition
Parking Lights - Must use a diode
Starter
Tachometer
9 403.MIT5 1.06 2018 Mitsubishi RVR (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Description
(-) Unlock Input
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(-) Ground When Running (Status) Input
Color
Green
Black
Blue
Red
Color
N/A
N/A
Connects To
Wire Location
Dash Fuse Box, black 2 pin plug (C-408), pin 1
Dash Fuse Box, white 15 pin plug (C-417), pin 7
Dash Fuse Box, white 16 pin plug (C-410), pin 12
Dash Fuse Box, white 15 pin plug (C-417), pin 6
Dash Fuse Box, white 20 pin plug (C-413), pin 10 (L);
pin 13 (R)
Dash Fuse Box, white 19 pin plug (C-415), pin 7
Any Fuel Injector, gray 2 pin plug, pin 2
Connects To
Wire Location
Remote Starter
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Remote Starter
(+/-) Wire Color
+ Black/Red (80A)
+ Green
- Pink
+ White
+ Blue (L); Pink (R)
+ Pink
AC Lt. Green, Yellow, Green, or White
(+/-) Wire Color
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
No Connection
No Connection
