Fronius Selectiva 4.0 Operating Instructions Manual page 27

NOTE!
Danger of damage to property due to heavy contamination of the charging plug
contacts.
Due to the increased contact resistance, overheating and subsequent destruction of the
charging plug can occur.
▶
Keep the charging plug contacts free of contamination and clean if necessary.
Connect the mains plug of the battery charger to the electrical network.
1
A prompt appears, asking whether the correct parameters have been set for the battery
to be charged.
The battery charger parameters are individually adjustable. Detailed information on the
battery charger parameters can be found in the "Configuration mode" section of the "Dis-
play" chapter. Make sure that the battery to be charged corresponds to the battery char-
ger configuration.
Plug in the charging plug.
2
The charger detects the connected battery and starts charging. If the start-up delay is ac-
tivated, the charging process starts after the set delay time has elapsed. Detailed inform-
ation can be found in the "Configuration mode" section of the "Display" chapter.
During the charging process, the display shows the following values:
- Current charging current (A)
- Current charging voltage (V)
- Charge delivered (Ah)
- Battery temperature with the "Temperature-controlled charging" option
- Time (hh:mm) from start of charge
The battery symbol indicates the current state of charge. The more bars are displayed,
the further the charging process has progressed. As soon as the battery is fully charged,
a minute counter appears (figure on the right). This counts the minutes since the end of
charging and makes it easier to judge which battery has cooled down the most when us-
ing several battery chargers.
If you still want the standard display to be shown instead of the minute counter:
Use the "Up/Down" buttons to switch between the minute counter and the standard
1
display.
The display then appears in standard
mode. The display shows the battery char-
ger parameters:
- Type of battery (e.g., Pb-WET)
- Charging characteristic (e.g., IUI)
- Nominal voltage (e.g., 48 V)
- Capacity (e.g., 300 Ah)
- Weekday, time, and date
27
