Argos Harrogate Multimedia CD760 Assembly Instructions Manual page 18

Components - Fittings
Note: The quantities below are the correct amount to complete the assembly. In some cases mor
may be supplied than are required.
A
50mm Screw x 12
D
Shelf support x 32
G
Wall plug x 1
Tools required
Phillips screwdriver
(medium & large)
Eye protection
(when using a
hammer or glue)
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30
3
B
Screw cover x 8
E
Wall strap x 1
35 40 45 50 55 60 65 70
(This screw is
included in the
wall strap bag)
x 1
75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
C
Nail x 36
F
14mm Screw x 1
Small
hammer
Ruler/tape
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
measure
0 1 2 3 4 5 6
