Capella - Dressing Table

Assembly Instructions -

Dimensions

Width - 81.6cm

Depth - 39cm

Height - 129.3cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

262/1982

267/6511

264/0877

227/5091

MADE IN

BRITAIN

Issue 6 - 16/10/14

Need help?

Do you have a question about the Capella and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Capella

Page 1 Capella - Dressing Table Assembly Instructions - 262/1982 Please keep for future reference 267/6511 264/0877 227/5091 Dimensions Width - 81.6cm Depth - 39cm MADE IN Height - 129.3cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 23kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (D1035A) (786 x 369mm) Right Side Left Side (D1034A) (D1033A) (744 x 390mm) (744 x 390mm) Modesty...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the holes shown on the back of the drawer front Note: Tighten the metal dowels up fully against...
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base along the grooves of the drawer sides into the groove of the drawer back Step 5 Note: The locking nuts can be on either surface of the drawer sides. Attach the drawer front Turn the drawer...
Page 7 Assembly Instructions Step 8 Prepare the left side Place 1 runner the left side . Slide back the top of the Profiled front edge runner and use the 1st hole from the front to fit the 1st screw Slide the runner back the other way and use the 3rd hole from the back to fit the 2nd screw...
Page 8 Assembly Instructions Step 9 Prepare the right side Place 1 runner the right side . Slide back the top of the runner and use the 1st hole from the front to fit the 1st screw Profiled front edge Slide the runner back the other way and use the 3rd hole from the back to fit the 2nd screw...
Page 9 Assembly Instructions Step 10 Prepare the top Tap 4 wooden dowels 10mm into the top shown. Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels. Insert 4 large locking nuts into the top as shown.
Page 10 Assembly Instructions Step 12 Prepare the modesty Tap 4 wooden dowels into the modesty Insert 4 large locking nuts into the modesty Step 13 Fit the modesty 2 people are needed here Attach the modesty to the right side Use a screwdriver to Finished tighten the 2 large edge...
Page 11 Assembly Instructions Step 14 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the top and the modesty Fit the 4 plastic nails Tap 2 plastic nails into the bottom edge of each of the sides Step 15...
Page 12 Assembly Instructions Step 16 Fit the drawer Slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners Working from the inside of the drawer, insert 2 screws through the drawer sides and out into...
Page 13 Assembly Instructions Step 17 Example Attach the Attach the Fit the overbalance Screw strap to the wall strap to the unit protector Washer Wall fixing Strap To prevent possible Strap (not supplied) overbalancing we Washer recommend that this unit is secured to a suitable Screw wall by use of the (not supplied)
Page 14 KEEP THESE INSTRUCTIONS FOR FUTURE USE If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
Page 16 ALR2995...
