Curve - Toy Box White
Assembly Instructions
Dimensions
Width - 80,6cm
Depth - 47,3cm
Height - 53,3cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800
- Please keep for future reference
377/3530
Issue 1 - 01/03/13
Advertisement
Related Manuals for Argos Curve 377/3530
Summary of Contents for Argos Curve 377/3530
- Page 1 Curve - Toy Box White Assembly Instructions - Please keep for future reference 377/3530 Dimensions Width - 80,6cm Depth - 47,3cm Height - 53,3cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 01/03/13...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly . Check you have all the . We do not This product contain components and tools listed on Natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below Front panel ( 72 x 44cm 01 Top panel ( 80,6 x 47,6cm Left side panel ( Base panel ( 44 x 43,4cm 72 x 43,4cm Right side panel ( 44 x 43,4cm Back panel ( 72 x 44cm...
- Page 4 If you have damaged or missing components, Components - Fittings call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Assembly Instructions Step 1 Insert wooden dowels into the indicated parts as shown. Insert wooden dowels into the left side panel and right side panel as shown. Step 2 CORRECT POSITION! Fix left side panel foot and foot using screws Parts...
- Page 6 Assembly Instructions Step 3 Correct position Fix right side panel foot and foot using screws Parts are labelled. Step 4 Fit base panel to left side panel . Then, fix it using screws...
- Page 7 Assembly Instructions Step 5 Fix back panel and front panel using screws PAINTED EDGE! Attention! Make sure panels are positioned as shown. Step 6 Correct position Fix right side panel to the assembled part using 9 screws...
- Page 8 Assembly Instructions Step 7 With help, turn cabinet upside down. Fix base panel to the front and back panels using screws as shown. With the help of a hammer, fix foot pads as shown. Step 8 Fix hinges to the top panel using screws...
- Page 9 Assembly Instructions Step 9 Fix top panel to the pre- drilled holes and through the hinges on the assembled cabinet using screws Step 10 Two people are required for an easier assembly. a) Fix locking system the pre-drilled holes on top panel using screws b) Fix locking system the pre-drilled holes on side...
